Exploring the Combustion Performance of a Non-road Air-Cooled Two-Cylinder Turbocharged Diesel Engine

1. Introduction

With the urgent need for energy conservation and emission reduction, improved performance of internal combustion engines becomes increasingly important. Due to the benefits of fuel consumption and thermal efficiency, small diesel engines are widely used worldwide in the non-road mobile machinery markets, especially household generators [1,2]. In addition, in the past decade, diesel generator sets, as a backup power supply source for hospitals, research institutes, signal towers and other facilities [3,4,5], have been developing in the direction of green and high-end, increasingly abundant fuels, such as ammonia[6] and methanol[7], are added to diesel to reduce emissions, so optimizing the combustion performance of diesel engines for generation sets is necessary.

In recent years, some scholars have studied the combustion performance of diesel engines according to combustion characteristic parameters. Ding et al. [8] conducted experimental research with a marine direct-injection diesel engine, providing a basis for engine combustion modeling. Saad et al. [9] used a wave model to investigate the effects of air-injection technology to improve turbo transient response from a heavy-duty diesel engine. Carlucci et al. [10] stated that compression and air-fuel ratios are important parameters affecting engine combustion performance, output power and specific fuel consumption. Taghavifar et al. [11] evaluated the performance of a turbocharged diesel engine under different compressor pressure ratios. It indicated that increasing the compressor pressure ratio could significantly improve engine efficiency and reduce fuel consumption. Liu et al. [12] studied the influence of pressure ratio and temperature ratio on the thermal efficiency and exergy efficiency of marine diesel engines. It was found that at a constant temperature ratio, the thermal efficiency first increases by increasing the pressure ratio, then decreases with the further growth of pressure ratio. Besides, the combustion chamber shape could directly affect the diesel engine's combustion performance. Annamalai et al. [13] transformed the hemispherical combustion chamber into a ring combustion chamber, effectively improving combustion performance. Singh et al. [14] found that the in-cylinder temperature could improve as the compression ratio increases from 15 to 18. Moreover, appropriate injection timing is a key parameter to increase the maximum convection flow by about 15%. Menacer et al. [15] found that the convection heat transfer characteristics could be greatly affected by the injection timing in a 6-cylinder turbocharged diesel engine. Liu et al. [16] found that by advancing injection timing from -1.6 °CA to -6.7 °CA in a turbocharged diesel engine, the exergy efficiency and heat transfer exergy could increase significantly. Pehlivan et al. [17] found that at full load, a change in injection timing from -4°CA to 2°CA resulted in a reduction in exergy efficiency from 43.45% to 41.36%. In addition, an increase in scavenging inlet temperature from 300K to 340K results in a decrease in exergy efficiency from 42.83% to 41.44%. Li et al. [18] conducted experiments on a six-cylinder turbocharged diesel engine and found that optimizing injection timing and pressure could reduce the vibration and improve the stability of the diesel engine.

Based on the findings above, it was proved that the power and combustion performance of heavy-duty turbocharged diesel engines are strong and can be further improved. However, due to relatively high noise and low economy, few applications in the field of generators [19,20]. Especially for small generator sets, in order to meet the demand of fuel economy, the selected type is usually single-cylinder and two-cylinder diesel engines. Many studies have been conducted regarding improving the overall efficiency of a small diesel engine in academia.

Wu et al. [21] designed a variable cross-section dual-channel chamber and optimized the swirl rate, fuel consumption rate, and emission performance in a single-cylinder diesel engine. Singh et al. [22] conducted experiments on a two-cylinder diesel engine to explore the feasibility of low-temperature combustion, where the combustion phasing is an important parameter in the combustion process. Ni et al. [23] conducted an external characteristic experiment on a two-cylinder diesel engine, and found that Brake Specific Fuel Consumption (BSFC) could be significantly reduced by about 6% by improving the combustion chamber. It is found that properly reducing the nozzle tip and increasing the nozzle aperture could reduce fuel consumption and smoke emissions. Ju et al. [24] used a two-cylinder diesel engine for small power generation and found that under 100% load, appropriate advance injection time can reduce BSFC by 1.84% and increase power by 1.88%. In order to understand the effect of intake air temperature on diesel engine performance and emissions, Pan et al. [25] conducted an experiment on a six-cylinder supercharged and intercooled diesel engine. The results show that the decrease of inlet air temperature will prolong the ignition delay time, lead to the delay of combustion time and the decrease of cylinder peak pressure. Lee et al. [26] found that the in-cylinder temperature and brake thermal efficiency decreased with the increase of intake pressure during the operation of dual-fuel diesel engines. Several novel findings to improve diesel engine performance were also provided by numerical research. Recently, Silva et al. [27] optimized the structure of the intake manifold based on the one-dimensional GT-POWER simulation platform. According to the change law of the volumetric efficiency curve of the intake manifold, the variable collection structure of the intake manifold is proposed, which provides a reliable scheme for improving the volumetric efficiency and torque of the engine and reducing the braking fuel consumption. Bogdanowicz et al. [28] simulated two fuel injection modes in a constant volume combustion chamber. It was found that proper peripheral fuel injection reduced heat loss and increased heat release rate compared to conventional diesel combustion. Moreover, air-cooled has been an important cooling method for small diesel engines due to the major benefits of simple structure, low cost and weight [29,30]. However, there is a lack of research on systematically exploring the combustion characteristics of small air-cooled diesel engines. Therefore, it is important and valuable to undertake a quantitative study on the combustion performance of a non-road air-cooled two-cylinder turbocharged diesel engine.

In this paper, the combustion characteristics of a non-road air-cooled two-cylinder turbocharged diesel engine were studied by exploring the effects of intake air conditions, combustion chamber shape, compression ratio and fuel injection timing. The study could provide novel insights and reliable data to effectively improve the performance of non-road small diesel engines, strengthening the green and sustainable development of diesel engines for generation sets. The study could provide novel insights and reliable data to effectively improve the performance of non-road small diesel engines, strengthening the green and sustainable development of diesel engines for generation sets. The findings of this study also have the potential to offer new insights for promoting the sustainable development of diesel engines used in generator sets.

2. Setup and Methods

2.1. Experimental Setup

Figure 1 shows the test bench diagram for the air-cooled two-cylinder turbocharged diesel in this study. The basic parameters of the engine can be seen in Table 1. The output end of the diesel engine is connected to a small electric dynamometer. The dynamometer is capable of providing a maximum speed of 3600 r/min and a maximum power of 22 kW. The JP60A turbocharger, which compressor diameter and turbine diameter is each 33 mm and 32 mm, was used to improve the intake condition of the diesel engine. Other main equipment parameters and sensor measurement progress are shown in Table 2. The diesel engine is connected to the dynamometer by a cone structure of the output shaft, which is bolted to a steel platform with a damper. The signal of cylinder pressure was measured by the Kistler-6050A sensor with a test accuracy of ±0.3% and analyzed combustion by analyzer CA3004A21 with the measurement error is ±0.5%FS. The speed signal comes from the speed sensor, and the speed signal is the magnetoelectric signal of 60-2, the measurement error is ±1 rpm.

2.2. Experimental Procedures and Key Parameters

The experimental object is an air-cooled two-cylinder diesel engine for power generation. During the test, a dynamometer was used to control the engine test conditions, including engine speed and load, according to the “Limits and measurement methods for non-road diesel engine specific fuel consumption” (GB/T 28239-2020), which were arranged as shown in Table 3. In each experimental condition in this test, the engine speed was fixed at 3000 r/min based on the requirement of generator sets. In order to improve the measurement precision of results, the experimental data were recorded after 10 minutes of stable operation, and the results of engine combustion characteristics were calculated and averaged according to 200 consecutive cycles. Moreover, the experimental boundary conditions were strictly controlled, as presented in Table 4.

Figure 2 is depicted to help explain the experiment approach of this study. Before the experiment, the sensor and measuring instrument should be calibrated to ensure the accuracy and reliability of the test data. Also, the consistency of environmental conditions should be checked. Then, the engine and test instruments should be preheated. The test data were measured and recorded after the engine ran stably for ten minutes at least. Finally, the engine combustion performance can be evaluated by analyzing the test data. Regarding the experiment, the first step is to analyze the effects of the combustion chamber shape, as a properly designed shape is very beneficial to enhance the mixing of diesel and air by forming eddy currents [31]. As shown in Fig 3, the Modified Combustion Chamber (MCC) is deeper and wider than the original Standard Combustion Chamber (SCC). The diameter of the combustion chamber is increased from 48.7 mm to 50 mm and the depth from 12.5 mm to 14 mm, which will increase the volume of the combustion chamber. In order to keep the combustion volume unchanged, the diameter of the taper is reduced from 46.4 mm to 43.8 mm. Moreover, the radius and dip angle of the pits become larger, while the shrink is smaller. At the same time, the curve of the central convex of the MCC is smoother, and the appropriate cone angle makes it easier for fuel and air to diffuse and mix. Meanwhile, the engine compression ratio and fuel injection timing were fixed at 19.5 and -17°CA, respectively.

In the second step of the experiment, the effects of the compression ratio of 18.5, 19.5 and 20.5 were studied. Meanwhile, the chamber is MCC, and the injection timing was kept at 17°CA. Then, in the third step, the effects of injection timing conditions of -20°CA, -15°CA, -13°CA, -10°CA and -5°CA were investigated under the conditions of MCC and 19.5 compression ratio.

2.3. Simulation Procedures and Key Parameters

To further investigate the combustion performance of the engine, a one-dimensional simulation model was used to conduct simulation works for the engine. Figure 4 shows the flowchart of the simulation approach. Firstly, a one-dimensional simulation model was built according to the experimental bench of Figure 1. The model parameters of the engine specifications and boundary conditions were set according to the details in Table 1 and Table 4. Then, the intake pressure was set to 0.1 MPa, and the effects of intake temperature from 230 K to 330 K with intervals of 20 K were simulated. Finally, the intake air temperature was kept at 280 K, and the effects of intake air pressure from 0.1 MPa to 0.06 MPa were numerically studied.

Various engine intake air conditions were quantitively studied, including extreme temperatures and different intake pressure. The key combustion parameters, including maximum cylinder pressure ($P_M$), maximum cylinder temperature ($T_M$), the Crank Angle (CA) of maximum cylinder pressure (${\phi }_{Pmax}$) and the CA of maximum cylinder temperature (${\phi }_{Tmax}$), were systematically analyzed.

The combustion process of a diesel engine includes the ignition delay period, the combustion duration period and the post-combustion period, among which the ignition delay affects the uniformity of diesel fuel mixing. The more evenly the fuel and air mix, the more fully the combustion is, and then the combustion duration is shortened. However, shortening the combustion duration can easily increase the explosion pressure in the cylinder and reduce its durability. In this paper, CA10, CA50 and CA90 are the crankshaft rotation angle corresponding to 10%, 50% and 90% combustion processes, respectively. From the beginning of fuel injection to CA10 is taken as the ignition delay, and the crankshaft angle between CA10 and CA90 is defined as the combustion duration. Besides, $P_M$ is introduced to denote the maximum in-cylinder pressure, ${\phi }_{Pmax}$ is defined as the crank angle of the $P_M$. $T_M$ denotes maximum in-cylinder temperature, ${\phi }_{Tmax}$ is defined as the crank angle of the $T_M$.

The combustion process has an important effect on the performance of diesel engine, and the heat release rate is the key parameter in the combustion process [32]. Wiebe combustion model is used to express the premixed combustion and diffusion combustion stages, Novaes et al. have shown that Wiebe function parameters have a direct effect not only on engine pressure and temperature, but also on engine performance, and the combustion model is shown in Equation (1) [33]:

$$x_b\left(\theta \right)=\lambda \left\{1-exp\left[-a_1{\left({\displaystyle \frac{\theta -{\theta }_0}{∆{\theta }_1}}\right)}^{m_1+1}\right]\right\}+\left(1-\lambda \right)\left\{1-exp\left[-a_2{\left({\displaystyle \frac{\theta -{\theta }_0}{∆{\theta }_2}}\right)}^{m_2+1}\right]\right\}$$

(1)

Where, $x_b\left(\theta \right)$ denotes the percentage of total mass fraction burned, θ denotes the crank angle corresponding to the top dead center time, ${\theta }_0$denotes the crank angle corresponding to the starting point of combustion. $∆{\theta }_1$ and $∆{\theta }_2$denote the combustion duration of premixed combustion mode and diffusion combustion mode, respectively. $m_1$ and $m_2$ denote the form factor of premixed combustion mode and diffusion combustion mode, respectively. $a_1$ and $a_2$ denote the efficiency parameter of premixed combustion mode and diffusion combustion mode, respectively. $\lambda$ denotes the weight factor.

The heat release rate is determined by cylinder pressure data, which is generally used to observe the combustion and heat. Assuming that air and fuel form a uniform mixture in the cylinder and are under uniform temperature and pressure during combustion, the heat release rate is determined by Equation (2) [34]:

$$dQ={\displaystyle \frac{\gamma }{\gamma -1}}\left(PdV\right)+{\displaystyle \frac{1}{\gamma -1}}\left(VdP\right)+d{Q}_w$$

(2)

Where, $dQ$ is the heat release rate (J/°CA), $\gamma$ is the specific heat ratio, $P$ is the cylinder pressure (Pa), $V$ is the instantaneous volume of the cylinder, and $d{Q}_w$ is the heat transfer rate.

In the process of engine operation, the state of the working medium in the cylinder is represented by three parameters, p, T and m, which are controlled by the mass conservation equation, the energy conservation equation and the ideal gas state equation.

Mass conservation equation:

$${\displaystyle \frac{dm}{d\phi }}={\displaystyle \frac{d{m}_B}{d\phi }}+{\displaystyle \frac{d{m}_s}{d\phi }}-{\displaystyle \frac{d{m}_E}{d\phi }}$$

(3)

Where, $m_s$ is the mass of gas in the cylinder, $m_E$ is the mass of gas discharged from the cylinder, and $m_B$is the mass of fuel entering the cylinder.

Energy conservation equation:

$${\displaystyle \frac{d\left(mu\right)}{d\phi }}={\displaystyle \frac{d{Q}_B}{d\varphi }}+{\displaystyle \frac{d{Q}_W}{d\varphi }}-P{\displaystyle \frac{dV}{d\varphi }}+h_s{\displaystyle \frac{d{m}_s}{d\varphi }}+h_E{\displaystyle \frac{d{m}_E}{d\varphi }}$$

(4)

Where, V is the working volume of the cylinder, m is the mass of the working medium, P is the transient pressure of the cylinder, $h_s$ and $h_E$ are the specific enthalpy of the working medium at the inlet and exhaust valves, $Q_B$ is the heat released by the fuel, and $Q_W$ is the heat of the cylinder.

Equation of state of ideal gas:

$$PV=mRT$$

(2)

Where, R is the gas constant and T is the gas temperature in the cylinder.

3. Results and Discussion

In this study, the intake conditions, combustor shape, compression ratio, and injection timing were chosen as the research conditions to study the influence of external environment and internal factors on combustion performance. In order to display the in-cylinder combustion process, cylinder pressure, heat release rate, ignition delay period, and combustion duration were selected as the combustion characteristics parameters.

3.1. Simulation Model Verification

In order to verify the accuracy and reliability of the model before optimizing the engine, the cylinder pressure and heat release rate were verified at 100% of engine load, 3000 r/min and 18.5 compression ratio, as shown in Figure 6. Although the experimental results could be affected by various environmental factors, the curves of simulation and experimental results match very well. Among them, the maximum value of the cylinder pressure curve corresponding to the simulation and the crankshaft Angle corresponding to the maximum value are each 3.3°CA and 9.952 MPa in the simulation. While, the corresponding values in the experiment are 4.4°CA and 9.874 MPa, respectively. The differences are 1.1°CA and 0.077 MPa, respectively, with percentages of error of about 0.31% and 0.78%, and the difference is within the acceptable range. The maximum heat release rate and crank angle in the simulation are each 23.16 J/CA and 7.7°CA. And, the corresponding values are 20.67 J/CA and 11.2°CA, respectively. Hence, the accuracy of this simulation model was quite acceptable with reference to the model validations in some other research [35,36,37].

3.2. Effects of Intake Air Conditions

Figure 7 and Figure 8 mainly illustrate the effects of intake air temperature from 230 K to 330 K on cylinder pressure, cylinder temperature, $P_M$ and $T_M$.

As shown in Figure 7 (a), the cylinder pressure shows a downward trend with the increase of intake air temperature. It can be found in Figure 8 that when the intake air temperature is 230 K and 270 K, $P_M$ can reach 12.03 MPa and 10.26 MPa, respectively. However, by increasing the intake air temperature to 330 K, $P_M$ is reduced to only 8.86 MPa. With every 20 K increase in intake air temperature, the gap between the $P_M$ of adjacent curves becomes smaller, which are 1.02 MPa, 0.75 MPa, 0.58 MPa, 0.47 MPa and 0.35 MPa, respectively.

Figure 7 (b) shows the cylinder temperature curves under different intake air temperatures. Consequently, the overall development process of cylinder temperature can be beneficial. As can be seen from Figure 8, with the increase of intake air temperature, $T_M$ also gradually increases, but the increased range obviously decreases. And from 230K to 250K, $T_M$ increases by 26 K, while the 310 K to 330 K value increases by 18 K, which is consistent with the change law of the $P_M$. However, the intake air density could be significantly reduced under high intake air temperature conditions. Hence, the heat release rate would be diminished due to decreased oxygen amount during combustion.

Figure 9 shows the effects of intake air temperature on combustion duration, ${\phi }_{Pmax}$ and ${\phi }_{Tmax}$. Regarding combustion duration, the values are relatively similar across different intake air temperatures, implying that the overall change in combustion heat release is not substantial. In the meantime, with the intake air temperature increase from 230K to 330K, ${\phi }_{Pmax}$ and ${\phi }_{Tmax}$ have delayed by 1.35°CA and 5.89°CA, respectively. Hence, the combustion center of gravity shifts rearward, improving the combustion performance.

Under actual working conditions, intake air pressure would be gradually reduced with the increase of altitude. Figure 10 (a) shows the cylinder pressure curves under different intake air pressures. Meantime, the intake air temperature is fixed at 280 K.

Unlike the effects of intake air temperatures, the cylinder pressure shows a consistent trend with the change of intake air pressure. With the decrease of intake air pressure from 0.1 MPa to 0.06 MPa, the cylinder pressure also gradually decreases. As shown in Figure 11, $P_M$ can reach 9.95 MPa at 1 bar intake air pressure, but it is only 4.84 MPa at 0.06 MPa. This is mainly because that a lower intake pressure, corresponding to a higher altitude, would deteriorate both intake air amount and combustion performance, reducing cylinder pressure.

Figure 10 (b) shows the cylinder temperature curves under different intake air pressures. At the macro level, the cylinder temperature shows an upward trend by decreasing intake air pressure from 0.1 MPa to 0.09 MPa. It can also be seen that the corresponding $T_M$ in Figure 11 increases from 1381.4 K to 1437.1 K. This is mainly because by decreasing intake air pressure, the reduction of intake oxygen amount could adversely affect the heat release rate, leading to a prolonged combustion period with a higher cylinder temperature. Then, by further decreasing intake air pressure from 0.09 MPa to 0.06 MPa, the variation of cylinder temperature generally shows a stable trend. The corresponding $T_M$ ranges from a relatively narrow interval around 1445 K. That can be attributed to a combined effect of two main factors. First, the lower oxygen amount could extend the combustion process, benefiting the cylinder temperature. Second, reducing the oxygen amount would deteriorate the combustion performance, suppressing the upward trend of cylinder temperature.

Figure 12 shows the effects of intake air pressure on combustion duration, ${\phi }_{Pmax}$ and ${\phi }_{Tmax}$.

The variation in combustion duration between different intake pressures is very slight. By decreasing intake air pressure from 0.1 MPa to 0.06 MPa, ${\phi }_{Pmax}$ and ${\phi }_{Tmax}$ first postpone, then become relatively stable. It indicates that with the decrease of intake air pressure, although the combustion duration is not apparently affected, the reduced oxygen amount still has the potential to prolong the whole combustion process, delaying the peak of cylinder pressure and temperature.

3.3. Effects of Combustion Chamber Shape

Figure 13 (a) shows the effects of two combustion chamber structures on cylinder pressure under 100% engine load. It can be seen that the maximum cylinder pressure of the MCC condition is 0.22 MPa lower than that of SCC. This is mainly because, in the premixed combustion and diffusion combustion period, a wider and deeper chamber is helpful to promote the form of eddy currents, enhancing the fuel spray atomization. As can be seen from the heat release rate curve in Figure 13 (b), due to the rapid formation of mixture in the MCC and the advance of premixed combustion, the concentrated heat release was earlier than the SCC, the heat release center moved forward, the cylinder pressure reached the peak in advance, and the heat load of the diesel engine is reduced. The decreasing released heat and pressure is helpful to reduce the entire engine's heat load, enhancing the engine's durability.

Figure 14 presents the comparison of the ignition delay and combustion duration between the SCC and MCC. It can be seen that, compared to SCC condition, the ignition delay and combustion duration for MCC under 100% load are extended by about 1.6 degrees and 4.2 degrees, respectively. Under 75% load, the ignition delay extended around 1.6 degrees, but the combustion duration is almost the same. Regarding lower engine loads (25% and 50%), the ignition delay and combustion duration are not apparently affected by modifying the combustion chamber shape.

3.4. Effects of Compression Ratio

Figure 15 presents the results of cylinder pressure and heat release rate under different compression ratios under 100% engine load. Overall, it can be seen that a higher compression ratio would be beneficial to increase the cylinder pressure [38]. The pressure curve's peak grows from 9.87 MPa to 10.47 MPa by increasing the compression ratio from 18.5 to 20.5. Regarding the heat release rate, under the condition of the 18.5 compression ratio, the combustion situation becomes worse, and the heat release rate is far less than the other two curves. Comparing the conditions between 19.5 and 20.5 compression ratios, there is no obvious change in the heat release rate curve. This is mainly because the corresponding compression clearance height is reduced as the compression ratio increases. Hence, when the piston approaches TDC, the cylinder pressure rises sharply, and the pressure difference of different compression ratios also expands. The temperature and pressure of the mixed gas in the combustion chamber could further increase at the end of the compression stroke.

Figure 16 presents the comparison of the combustion period under three compression ratio conditions. With the increase of compression ratio, all the three kinds of periods (CA10, CA50 and CA90) are advanced on the whole. Compared to the 18.5 compression ratio, CA10 under the conditions of 19.5 and 20.5 compression ratios are advanced by 3.3°CA and 5°CA, respectively. Meanwhile, CA50 and CA90 can each be advanced by around 6.5°CA and 3.8°CA by increasing compression from 18.5 to 20.5. Figure 16 shows that the ignition delay can be shortened by increasing the compression ratio, leading to higher cylinder pressure and heat release rate. Besides, the combustion duration remains relatively stable under different compression ratio conditions.

3.5. Effects of Injection Timing

Figure 17 to Figure 18 mainly present the effects of injection timing on cylinder pressure and heat release rate under 100% engine load. It can be found that with the advance of injection timing, the cylinder pressure generally shows an increasing trend in Figure 17 (a). $P_M$ could reach the maximum value of 11.4 MPa under the condition of -20°CA injection timing, as shown in Figure 18. In addition, CA50 is delayed with the advance of injection timing, indicating that the center of gravity of combustion moves backward, which is conducive to full combustion and improving exergy efficiency14，15.

By analyzing Figure 17 (b), it can be found that the distribution of heat release in the cylinder is relatively similar before the top dead center. This is mainly because advancing injection timing will help extend the ignition delay period, thus increasing the heat release proportion in the premixed combustion stage.

Figure 19 mainly shows the effects of injection timing on ignition delay and combustion duration under different loads. In Figure 19(a), it can be seen that at 100% load, compared to the engine's original injection timing of -17°CA, the ignition delay period is shortened by 1.4 degrees when the injection timing is advanced to -20°CA. With the further delay of injection timing from -17°CA to -13°CA, the ignition delay is each shortened by 3.8 degrees, 3.87 degrees and 2.48 degrees under 100%, 75% and 50% loads, respectively.

Moreover, as presented in Figure 19(b), with the delay of the injection timing, the extension of the combustion duration is conducive to the full combustion of the fuel. Significantly, under 100% load, compared to the engine's original injection timing of -17°CA, the combustion duration is extended by 12.24 degrees under -5°CA injection timing. However, the excessive combustion duration may lead to higher vibration and noise, reducing the diesel engine's durability. While under middle and low loads, especially 25% load, the combustion duration are less affected by injection timing.

4. Conclusions

In this study, the effects of the combustion chamber, compression ratio and injection timing on the combustion performance of a non-road air-cooled two-cylinder turbocharged diesel engine were studied. First, the effects of intake air conditions were numerically investigated. Then, by experimental methods, the combustion performance is studied by changing the shape of the combustion chamber, followed by exploring the effects of different compression ratios and injection timing based on the MCC. The main results can be summarized as follows:

(1) With the increase of intake air temperature from 230 K to 330 K, the cylinder pressure decreases while $T_M$ gradually increases. Meantime, ${\phi }_{Pmax}$ and ${\phi }_{Tmax}$ are each postponed by 1.35°CA and 5.89°CA, which would benefit the engine combustion performance.

(2) By reducing intake air pressure from 1 bar to 0.6 bar, combustion performance would be obviously deteriorate mainly due to the lower intake oxygen amount. $P_M$ has a marked decline from 9.95 MPa to 4.84 MPa, and $T_M$ has a small increase from 1381.4 K to 1437.1 K. ${\phi }_{Pmax}$ and ${\phi }_{Tmax}$ initially experience a delay, followed by a relatively stable variation.

(3) After replacing SCC with MCC, cylinder pressure and heat release rate would be reduced, which could benefit the engine's durability due to lower heat load. Moreover, the ignition delay and combustion duration are each extended by 1.6 degrees and 4.2 degrees under 100% load. Under 75% load, there is a small extension of around 1.6 degrees for the ignition delay, and the combustion duration is almost same. Under relatively low engine loads (25% and 50%), compared to MCC condition, both ignition delay and combustion duration modifications remain largely unchanged under SCC condition.

(4) Under 100% engine load, the effects of engine compression ratio were explored. By increasing the compression ratio from 18.5 to 20.5, the peak cylinder pressure rises from 9.87 MPa to 10.47 MPa. Compared to 18.5 compression ratio condition, there is a marked improvement in heat release rate under higher compression ratios. Moreover, with the increase of compression ratio, CA10, CA50 and CA90 can be advanced, and the ignition delay can be shortened.

(5) By advancing injection timing to -20°CA, the peak cylinder pressure can increase up to 11.4 MPa, and the ignition delay is shortened by 1.4 degrees under 100% load. By delaying the injection timing, the prolonged combustion duration facilitates the thorough combustion of the fuel. Particularly, under a 100% load, compared to the engine's original injection timing of -17°CA, the combustion duration extends by 12.24 degrees under a -5°CA injection timing. Meanwhile, under middle and low loads, the effects of injection timing on combustion duration become quite weak.
