Gastric Perforation from Bag-Valve-Mask Ventilation Resulting in Tension Pneumoperitoneum and Arterial Insufficiency

1. Introduction

Gastric distention is a known complication of therapeutic oxygen delivery with multiple contributing factors including excessive force, volume, or frequency of air delivery. A retrospective study of 446 computed tomography (CT) scans taken after cardiopulmonary resuscitation (CPR) with bag-valve-mask (BVM) ventilation found median gastric air accumulation volumes of 400 mL [1]. In severe cases, air accumulation rates and volumes are sufficient to cause stomach perforation. While gastric distention from therapeutic oxygen delivery rarely progresses to perforation, there is a small body of literature of such cases with etiologies including bag-valve-mask (BVM) ventilation, accidental esophageal intubation, and mouth-to-mouth resuscitation [2]. When the stomach perforates, high gastric pressure causes air leak into the peritoneum causing pneumoperitoneum. A subset of these perforation cases further exhibit a phenomenon known as tension pneumoperitoneum, where the site of gastric rupture acts as a one-way valve allowing further air accumulation in the peritoneum but preventing air escape [3]. In the most severe cases of tension pneumoperitoneum, intraabdominal pressures are sufficiently high enough to compress the aorta, reducing blood flow to vital organs and the lower extremities. However, there are few descriptions in the literature of arterial insufficiency as a sequela of gastric rupture from therapeutic ventilation.

2. Case Presentation

A 44-year-old female with a past medical history of cocaine, alcohol, and cannabis use disorder was brought in by emergency medical services (EMS) with the chief complaint of altered mental status in the setting of alcohol intoxication. According to history obtained from her partner in the field, she consumed approximately 10 small bottles of Fireball whiskey and subsequently experienced sudden-onset abdominal pain and confusion. The EMS report on arrival found her to be “naked on the ground, altered and combative”. Due to the unsafe nature of the patient’s behavior, her lacking medical capacity, and an inability to transport safely, 2.5 mg of droperidol was administered intramuscularly. When this did not cause any change in the patient’s condition, 2.5 mg of midazolam was administered and calmed her down. Her initial Glasgow Coma Scale in the field was 15 without any intubation, and her vitals remained stable and within normal limits en route to the emergency department (ED). In the field and enroute to the hospital, she was ventilated via BVM.

Upon arrival in the ED, patient was combative. Initial vitals were within normal limits, including a blood pressure of 110/70 and heart rate in 70s. Urine and serum toxicology tests were positive for cocaine, hydrocodone, cannabinoids, and alcohol (serum level 312 mg/dL). She was found to have a significantly distended abdomen described as “rock-hard” to palpation. A lower extremity exam revealed dusky appearing feet that were cool to touch, non-palpable dorsalis pedis pulses, and 1+ radial pulses bilaterally. Bedside ultrasound revealed air in all abdominal quadrants. Subsequent expedient computed tomography angiography (CTA) revealed tension pneumoperitoneum with compression of the vena cava and aorta and presence of pneumatosis intestinalis diffusely throughout the small bowel (Figure 1a-d).

With the ultrasound and CTA results coupled with physical exam findings of lower extremity arterial insufficiency, an orogastric tube (OGT) was placed returning frank blood. Additionally, emergent needle decompression of the abdomen was performed with a paracentesis catheter, which was left on suction in the left side of the abdomen. Well over 2 liters of air was removed from the peritoneum. Within one minute of needle decompression, there was return of dorsalis pedis pulses and color to bilateral lower extremities. However, within minutes of decompression, the patient showed signs of respiratory distress with SpO₂ declining to the 80% range. To support declining respiratory status, the patient was endotracheally intubated five minutes after needle decompression was performed. The trauma surgery service was consulted, and the patient was treated supportively with a 1-liter lactated ringers IV bolus, norepinephrine infusion with a 0.15 mcg/kg/min rate, and 3.375 grams of piperacillin-tazobactam antibiotic.

The patient’s status continued to decline with a sudden drop in systolic BPs to the 80s. A decision was emergently made to intervene with exploratory laparotomy. Pre-operatively, the lactate was 4.3, VBG showed pH of 7.21. Immediately upon incision of midline abdominal fascia, a rush of blood escaped from the abdomen. All four quadrants were opened and packed with 30 total laparotomy pads. 600 mLs of blood was suctioned in the process. Anesthesia was then given time to resuscitate and administer blood products before removal of any packed pads from the abdomen. A left sided Cordis catheter was placed for transfusion. However, it was immediately found to be pulsatile and in the femoral artery rather than vein. This was left in place due to the patient’s coagulopathic state. Anesthesia subsequently placed a central venous catheter through which two units each of packed red blood cells (pRBCs) and fresh frozen plasma (FFP) were transfused, stabilizing blood pressures. Removal of the laparotomy pads revealed perforation at the lesser curvature of the stomach with hemorrhage from the left gastric artery and veins. A Ligasure device was used to stop bleeding at these vessels and others around the stomach. A subtotal gastrectomy was performed using a gastrointestinal anastomosis stapler, with the superior stomach and duodenum left in discontinuity. The abdomen was then washed out extensively. The wound was left open and covered with an AbThera Negative Pressure Wound Therapy.

Post-operatively in the ICU, the patient showed signs of multi-organ failure (ALT 1489, K 5.6, Cr 3.7, Ca 6.4), severe metabolic acidosis (pH 6.9, lactate 15), distributive shock (systolic BP in 60s, temperatures below 32°C (90°F)), and DIC (INR 3.71, platelets 73). Despite treatment with broad spectrum antibiotics, continuous renal replacement therapy, and maximal use of pressors, the patient ultimately developed asystole and passed away approximately three days after initial presentation.

3. Discussion

This patient’s presentation with dusky lower extremities, lack of palpable lower extremity pulses, and CTA findings of a compressed aorta suggest severe tension pneumoperitoneum due to air entry and trapping at the site of gastric rupture. Initial needle decompression and drainage relieved symptoms of arterial insufficiency. However, high intraabdominal pressures created by the tension pneumoperitoneum had acted as a tamponade to stop bleeding from the site of gastric rupture. Removal of this tamponade is what likely led to more vigorous internal bleeding and hemodynamic instability within minutes. Similarly, the 30 laparotomy pads placed during exploratory laparotomy had acted as a temporary tamponade whose removal required transfusion of 2 units each of pRBCs and FFP.

Gastric distention is a common finding while providing therapeutic ventilation, making it challenging to identify cases which have progressed to perforated viscus and subsequent tension pneumoperitoneum. CTA can provide a definitive diagnosis but cannot help in the field and it is often too late for patients once they have made it a hospital. Return of frank blood from an OGT is a means of diagnosis of this complication [4], and some institutions in the past have reported using diagnostic peritoneal lavage (DPL) to assess for peritoneal bleed [5]. However, gastric blood from OGT does not definitively diagnose perforation as patients may have only developed gastric mucosal layer tears rather than complete gastric perforation. In fact, it is estimated that 9-12% of CPR patients develop mucosal tears, whereas instances of perforation are far rarer, requiring at least approximately 4 liters of accumulated gastric air [5]. DPL may also be inconclusive, especially in the setting of pressurized intraabdominal air slowing a gastric bleed. However, given the rarity in the literature with one prior case attributed to BVM ventilation, only the most severe cases of perforation develop the intraabdominal pressures necessary to compress the aorta and precipitate vital organ dysfunction [6]. This case suggests that assessing for adequate lower extremity perfusion is more rapidly informative and versatile than the traditional CTA, OGT, or DPL for identifying these severe cases. However, confirmatory imaging ought to be pursued before moving on to treatment due to other pathologies such as congestive heart failure with peripheral vascular disease that could also present with arterial insufficiency and abdominal distention. Nevertheless, lower extremity pulses and pallor can be used as a sign of life-threatening air accumulation that should be treated with immediate cessation of ventilation and preparation for needle decompression and exploratory laparotomy while awaiting imaging.

Once diagnosed, treatment for gastric rupture from therapeutic ventilation consists of needle decompression to provide immediate relief of intraabdominal pressures followed by subtotal or total gastrectomy. Prior cases recommend placement of a 14-gauge catheter midline and just inferior to the umbilicus [5]. Cases of tension pneumoperitoneum often resolve after needle decompression without ensuing hemodynamic stability as in the case presented, but exploratory laparotomy is still warranted to repair the stomach [7].

As in the case presented, barotraumatic gastric rupture usually occurs at the lesser curvature of the stomach, a pattern attributed to limited elasticity of the area due to fewer gastric folds and tethering by the nearby gastrohepatic ligament [2]. However, rupture along the lesser curvature, greater curvature, anterior wall, and posterior wall have all been reported in neonates [8].

Causes of gastric air accumulation are often related to improper BVM ventilation technique. In a review of 67 cases of gastric perforation resulting from therapeutic ventilation delivered as part of CPR, bystander delivery of CPR was the number one risk factor for perforation identified in 57% of cases [4]. Improper positioning can cause airway obstruction, which makes air passage down the esophagus and into the stomach more favorable. Lack of adequate jaw support in extension positioning has been identified as a possible cause of upper airway obstruction [9]. As such, head tilt and chin lift are key to relieving airway obstruction during BVM ventilation [10].

Any airway obstruction during BVM ventilation would also be likely worsened by the clinical state for requiring CPR. Although not the clinical picture in the case presented, lower esophageal sphincter pressure has been found to decrease from 20 cmH₂O to 5 cmH₂O during cardiac arrest, making gastric air accumulation more favorable [11]. Furthermore, patients requiring therapeutic ventilation exhibit hypoxia, leading to increased pulmonary airway pressures and decreased lung compliance, thus making it harder to ventilate the lungs [12]. One study utilizing swine models found a 30% decrease in lung compliance over the course of 15 minutes of ventricular fibrillation [13]. If given, chest compressions could also increase pulmonary airway pressures, favoring esophageal air accumulation [5]. Obesity, which was absent in the case presented (patient BMI 22.8), would have added additional difficulty in lung ventilation. Other factors that increase the odds of airway obstruction during BVM ventilation include old age due to loss of control of pharyngeal structures and obstructing tongue, tonsils, or uvula [10]. One case series of three patients with barotraumatic gastric rupture reported an association with prior use of antiplatelet drugs and anticoagulants [2].

Comparisons of different therapeutic ventilation delivery methods have shown BVM to be preferred to endotracheal intubation, mouth-to-mouth, and laryngeal mask airway for quickly establishing ventilation, particularly in pre-hospital settings [14]. However, compared to other ventilation delivery methods, BVM has a higher risk of gastric insufflation due to lower control over force, pressure, and volume of delivery [15]. This is exacerbated by use of BVM in high-stress resuscitations, where even healthcare professionals trained in airway management have been shown to routinely hyperventilate patients in the field with twice the number of breaths per minute as recommended by guidelines [16]. Nevertheless, other ventilation methods have also been associated with gastric rupture and generally involve more time and resources than BVM to deploy [4,9,17,18].

4. Conclusions

This case highlights the importance of early and frequent assessment of lower extremity perfusion while ventilating patients, particularly in resuscitation scenarios in the field. While ventilation-induced gastric barotrauma is rare, this case has broad applicability due to the relatively high number of ICU patients with intra-abdominal hypertension (IAH) from other causes. In all cases of IAH, distal perfusion assessment can be used as a sign of significantly elevated pressures with potential resulting multi-organ dysfunction and threat to life as exhibited in this case.
