Targeting Androgen, Thyroid Hormone, and Vitamin A and D Receptors to Treat Prostate Cancer

1. Introduction

Prostate cancer (PCa) is the second most common tumor in males. Hormone sensitivity is a trait Achilles heel of PCa whereby androgen deprivation therapy (ADT), which began in 1941, represents the core strategy of PCa treatment [1]. This treatment alone or with chemotherapy remains the standard therapy, but many patients progress to ADT-resistant tumors termed castration-resistant PCa (CRPC) which is mainly associated with amplifications, mutations and gene rearrangements to the androgen receptor (AR) [2,3]. The potentiation of AR in the CRPC setting historically constituted the rationale for combining ADT with drugs that either target androgen synthesis (abiraterone) or block the AR (enzalutamide and bicalutamide), leading to a beneficial clinical outcome [4,5,6]. Other steroidal hormone receptors, including the progesterone receptor [7], estrogen receptors (ERs) [8] and glucocorticoid receptor [9], have been implicated in PCa tumorigenesis and resistance development.

For PCa, we examine the influence of androgens, 3,5,3’-triiodo-L-thyronine (T3) stimulation of the thyroid hormone receptor (TR) β the use of synthetic retinoids to selectively antagonise the retinoic acid receptor (RAR) γ and activation of the vitamin D receptor (VDR) by 1α,25-dihydroxyvitamin D3 (1,25D3), the active metabolite of vitamin D3. We focus on the activation status of these receptors because they influence the proliferation of PCa cells whereby activity of AR, TRβ, and RARγ enhance PCa proliferation and active VDR drives growth arrest followed by apoptosis. We describe the current state of knowledge regarding the modes of action of the hormones and their receptors, particularly their interactions and the extent to which there is also regulatory crosstalk. A better appreciation of crosstalk is likely to offer new therapeutic possibilities, especially for hormone-dependent forms of cancer [10]. Our aim is to highlight the potential of targeting the above nuclear receptors (NRs) to treat PCa. There are extensive reviews of the roles of other NRs in PCa [11] including orphan nuclear receptors (ONR) [12].

2. Nuclear Hormone Receptors

2.1. The Functionalities

Hormones exert continuous control on gene regulation processes to ensure the proper functioning of all tissues and, therefore, the well-being of an organism. A hormonal imbalance due to an excess or a deficiency can lead to severe and sometimes life-threatening diseases. From studies of estrogen, it became clear that hormones act through NRs to regulate gene expression [13,14]. In 1985, the first full-length NR to be cloned was the human glucocorticoid receptor [15] and around the same time the estrogen receptor (ER) α was cloned [16]. Soon it became clear that these receptors are structurally similar and belong to a NR superfamily [10,17].

In addition to NR family members binding classical hormones, they also bind lipid-soluble ligands, including the most active metabilite of vitamin A all-trans retinoic acid (ATRA), 1,25D3, and oxysterols. Binding activates the essential role of NRs as transcription factors (TFs). Many NRs and their isoforms have been cloned and many of their regulatory cofactors have been identified. Presently, there are 48 genes for NRs and closely related orphan NRs (ONRs), and their phylogenetic classification is based on protein sequence homologies [12,14]. They all contain a highly conserved modular structure, and the evolutionary oldest family members function without ligands. Whilst much is known about NRs and their modes of action, information about their tissue- and disease-specific effects and their binding cistromes still needs to be discovered. Other poorly understood areas include the extent to which NRs interact and their potential mutual regulation.

2.2. Phylogenetical Features

NRs contain four main structural elements. They are the N-terminal domain (NTD), a gene transactivation domain which includes the DNA-binding domain (DBD), a flexible hinge region (H) which contains the nuclear localization motif (NLS), and a ligand-binding domain (LBD) [14,18,19]. NRs function as TFs in an allosteric manner, typically switching between an inactive (ligand-free) and an active (ligand-bound) form. An important feature of NRs is that they can act as monomers, homodimers, and heterodimers with other NRs [18,20]. Figure 1 showns how gene expression is driven by type I and type II NRs by canonical dimers.

The NRs are broadly divided into four types based on their functional characteristics and modes of DNA binding [20]. Type 1 are located in the cytosol and shuttle upon ligand-binding and homodimerization into the nucleus. They are steroid hormone-binding receptors and include AR, the glucocorticoid receptor (GR), the progesterone receptor (PR), the mineralocorticoid receptor (MR), and ERs. Type II NRs include the TRs, RARs, VDR, and peroxisome proliferator-activated receptors (PPARs). They are present in the nucleus and localised to chromatin as RXR heterodimers in a repressive mode. They become transcriptionally active when ligands are bound, which leads to the loss of corepressors and the recruitment of coactivators. Type III are the homodimeric orphan receptors, they shuttle as dimers, and bind to direct hormone response element (HRE) repeats. Type IV are the monomeric orphan receptors [18]. The four types of NRs have been considered as a putative target regarding therapies for PCa [21]. Proteomic studies have revealed the capacity of NRs to liaize with one another and various cofactors [22], creating a wide range of NR interactome possibilities. Crystal structure analyses have revealed non-canonical dimerisation and even multimeric forms [19], highlighting a high functional versatility. Figure 2 shows the structures of the AR, TR, RAR, and VDR genes and proteins.

2.3. DNA-Binding Motifs and Gene Expression Regulation

The NR regions relevant for DNA binding and heterodimerization were identified by inserting specific mutations, leading to the elucidation of the nucleotide nature of the DNA-binding motifs and characterisation of HREs [23]. Similar to other TFs, how NRs interact with chromatin depends on simple, highly conserved hexamer DNA-motifs. Ingeniously, their orientation and spacer regions lead to the fine tuning of binding capabilities [17,22,24]. Importantly regarding DNA response element binding, TR, VDR, and RAR bind as heterodimers with retinoid X receptors (RXRs), including pairing with RXRα, β or γ According to the 3-4-5 rule, these are always direct AGGTCA hexamer repeats, spaced by 3 nucleotides for the VDR, 4 nucleotides for TRs, and 5 nucleotides for RARs. There are other binding possibilities, including additions to the known “canonical” motifs. One site sequence would not be sufficient because a single transcription factor can recognise hundreds of DNA sequences, bind within a range of affinities, and local DNA structure is also essential [25]. All these parameters greatly expand the potential scope of gene expression regulation [26]. To add to this complexity, there are isoform variants of NRs and their multitude interactions, ligand- and DNA-binding capabilities result in regulatory possibilities that are still barely defined [27]. Finally, NRs regulate distinct genes in different tissues, and most probably, they are different in diseases due to pathophysiological changes.

3. Androgen Receptor

Androgen deprivation therapy is the gold-standard treatment for most PCa patients. However, CRPC, which is a highly aggressive metastatic hormone-independent form of the disease, develops in a significant number of patients. Treatment options for these patients are limited, even with the recent introduction of improved therapeutics.

3.1. The Functionalities of the AR

The AR gene is located at q11-12 on the X chromosome and encodes a 920 amino acid protein. Alternative splicing results in multiple transcript variants encoding different isoforms. As for all NRs, there are four main structural elements to the protein (Figure 2). Together with the GR), PR, and MR receptors, AR forms the oxosteroid superfamily, which is phylogenetically separated from the ERs and TRs [28]. The AR is a classical steroid hormone receptor whereby functionality is critically dependent on the presence of androgens. They are a group of steroidal sex hormones that are produced in the testes, the ovaries, and the adrenal glands and androgens are the main drivers of male sex development. Testosterone, the major androgen, is converted intracellularly to dihydrotestosterone (DHT), which has the highest affinity for the AR. Post-ligand binding, the AR forms homodimers which then translocate to the nucleus [29] to control gene expression by binding to inverted repeat androgen response elements (AREs) [24].

3.2. AR and Prostate Cancer

The role of AR in PCa is described exhaustively in numerous reviews [30,31]. The AR maintains a healthy prostate epithelium, including its proper differentiation. Overactivation alone does not lead to PCa [11], and instead the AR plays a role in conjunction with other malignant processes. In this case, correlating AR expression levels with the risk of PCa development is not significant.

AR contributes to tumour growth by driving the expression of genes that control cell proliferation. Whilst AR-mediated changes to PCa-associated gene expression are known, their contributions to PCa and dissemination still need to be fully understood. There are changes in extranuclear steroid hormone receptor signalling [32], and the AR, after shuttling to the nucleus, shows altered DNA binding capabilities, which reshapes the AR-driven cistrome. Since the canonical AR binding motif and its structure are highly conserved, this must be due to chromatin landscape changes and its accessibility, as was shown for the cadherin 1 gene [33].

During advanced malignant transformation, the role of the AR becomes increasingly essential. ADT drives the development of active AR variants without ligand binding. After an initial successful ADT treatment phase, PCa becomes “androgen-independent”, but remains dependent on active AR signaling, which is conferred by various mechanisms that include AR point mutations, gene amplifications, activating AR splice variants, truncated AR variants, and upregulation of AR co-activators [34]. Point mutations accumulated at the dimerization interface, which probably reflect higher stability of the resulting monomers [19], and AR splice variants activate distinct transcriptional programs [35]. Very late-stage PCa is characterized by complete loss of the AR. This fatal development has been strongly advanced by the use of highly effective AR inhibitors and degraders. Hence, treatment options that circumvent the development of this situation are urgently needed.

3.3. Crosstalk between AR and Other NRs/Transcription Factors

There are potential non-canonical AR interactions that have implications for PCa. Recent crystal structure data indicate a high flexibility of the core AR dimers which might form a head-to-tail or a head-to-head arrangement [36]. This non-canonical dimeric conformation theoretically opens up many more spatial possibilities for potential interactions with other NRs or the cofactors that associate to form the transcriptionally active AR complex [19]. Atypical dimers are considered very likely to exist [27], though they are less prevalent than the canonical ones. Moreover, when AR function is strongly suppressed during ADT, atypical dimers can become essential and might even overtake AR function. There are likely direct consequences regarding physical NR interactions/competitions at the level of DNA [27] and to the regulation of subsets of genes. Indirect modes of pathway interference might include perturbations to the expression of the other NRs and/or their ligands [27]. All these possibilities might substitute for reduced AR function during ADT or might drive PCa growth per se.

There is a crosstalk between the AR and other NRs. RAR was upregulated post-androgen treatment of LNCaP cells; this was controlled by an ARE promoter element and led to upregulation of the epithelial growth factor receptor [37]. Upregulation of the glucocorticoid receptor was observed as an effect of ADT in PCa [38,39]. Though PCa is primarily an androgen-dependent disease, there is the interplay between AR and ERs because androgens are aromatised to estrogens in adipose tissue, and the testosterone/estradiol ratio is essential to the development of PCa [40] (Figure 2). Low teststerone levels and high levels of estradiol lead to premalignant lesions providing evidence to support the importance of an imbalance to the ratio [41], and a high estradiol level in African-American men has been linked to a greater risk of developing PCa [42]. More recent work has focused on how estrogenic imprinting of the epigenome may contribute to PCa [43] and it has been argued that new compunds that target ERs might lead to therapeutic opportunities [44]. AR interacts with the PR regarding expression of the kallikrein-related peptidase 4 (KLK4). This protein is only expressed in PCa when there is expression of the AR and progesterone receptors. A hormone response element mediates gene expression whereby the progesterone receptor interacts directly with the gene promotor, and the interaction of AR is indirect [7].

There is cooperativity between AR signalling and PPARγ, whereby AR inhibits the expression of PPARγ (Figure 3). At first, PPARγ was viewed as a tumour suppressor for PCa, agonists were shown to inhibit PCa cell growth, but this was then found to be PPARγ independent. Recently, it has been reported that there is increased expression of PPARγ during PCa progression with higher protein levels in advanced PCa compared to low-risk disease and benign hyperplasia [45]. Findings support the view that PPARγ supports PCa cell growth by increasing the machinery for lipid synthesis, including cutaneous fatty acid-binding protein (C-FABP) [46], fatty acid synthase (FASN) and ATP citrate lyase (ACLY), and mitochondrial biosynthesis [47], bringing to attention that NRs regulate PCa metabolism. Upon loss of AR, antagonism of PPARγ may benefit the treatment of advanced stages of PCa. However, there is the need to take into consideration complexities relating to the different splice variants of PPARγ whereby increased PPARγ1 increased PCa tumorigenesis and FASN and ACLY expression whereas overexpression of PPARγ2 decreased LNCaP and PC3 proliferation and invasiveness [47].

Interaction of AR with tumor promoting signaling pathways has been observed, importantly with the Wnt pathway in CRPC [48]. Wnts are an ancient and conserved family of secreted glycoproteins that regulate the fate of developing cells [49]. Downstream of the binding of Wnts to frizzled is the activation of the TF β-catenin [50], which plays a role in various cancers including PCa [51,52]. Recently, a direct interaction of AR with GATA3 has been shown to regulate a luminal epithelial phenotype in breast cancer [53].

4. Thyroid Hormone Receptor

4.1. The Functionalities of TRβ

Thyroid hormone (TH) signaling is a primeval pathway. Though iodine is toxic to pathogens, including viruses, anaerobic bacteria, yeast and fungi, it is a crucial micronutrient [54]. It is taken up by single-cell species, such as photosynthetic bacteria and algae, as iodate which is converted to reactive iodide anions that have a high affinity for tyrosine [54]. Iodide coupling creates the highly reactive iodotyrosine signaling molecule. Virtually all organisms use iodine in this manner for use in essential biochemical tasks. The synthesis of THs evolved from iodotyrosines, which are present in all animal genera except arthropods [54,55]. THs regulate the growth and development in non-bilaterian animals, such as porifera (sponges) and cnidarians (medusae and polyps), and are present throughout lophotrochozoans (molluscs and worms) onwards [55]. Lophotrochozoans have a TH signaling system that is TR-mediated. Essentially, THs are important universally to the conduct of normal development. They provide a pro-survival stimulus and support metamorphosis in amphibians and lampreys and life-transitions in higher animals [56], and their effects are highly time- and dose-specific and depend on tissue type and developmental stage [57].

THs exert their effect in vetebrates via TRs. The TR-coding cDNA was identified as a homologue to the avian erythroblastosis virus v-erb-A oncogene [58].TR proteins are much shorter than the AR; TRα has 490 amino acids, and TRβ has 461amino acids. However, a vast variety of isoforms is generated by alternative splicing. TRs are stimulated by thyroxine (T4) and its active derivative T3. They form homodimers or act as heterodimers in conjunction with RXRs [59]. There are two main TR isoforms: TRα and TRβ. TRα is predominantly expressed in the heart, bone, and brain, whereas TRβ is more abundant in the liver, kidney and thyroid. TRα and TRβ seem to exert distinct tissue-dependent effects which are very likely complementary to each other, as revealed from studies of mutants [60]. Moreover, TRα and TRβ have opposing roles by differences in their molecular properties and modes of action [61], based on diverse DNA binding affinities [62].

Unlike the AR, TRs belong to the class II NRs and reside constantly in the nucleus as a heterodimer with RXR. The canonical TR pathway involves binding of TR/RXR to thyroid response elements (TREs), which are, as mentioned above, direct repeats of two hexamer DNA-motifs spaced by 4 nucleotides (DR4) [24]. This binding mode is highly fine tuned by the more specific DNA motifs [63]. Shuttling of T3 to the nucleus and binding to TRs attached to TRE elements in the genome leads to the loss of corepressors and the subsequent activation of gene transcription [64,65].

Further extensive analyses of TR DNA binding and potential ways of gene expression regulation have led to indications that there is gene regulation beyond canonical binding modes. TRs can bind to DNA as monomers [66], and dimeric variants have been described [19,67]. TRβ is the more interesting TR and the gene that encodes it is located at chromosome 3. It seems to act in a more versatile manner, and several missense mutations are reported, which, as for the AR, map to the homodimer interface and might lead to altered ligand or coregulator binding.

4.2. THs/TRβ and Prostate Cancer

THs contribute to vertebrate development with links to many endocrine systems, as seen from studies of zebrafish, birds, rodents and dogs [68,69,70,71,72]. There are indications that a close interaction between thyroid and gonadal hormone systems controls sex-determination and testicular development [73]. In particular, THs impinge on sexual differentiation and gonadal development in mammals: they are involved in the maturation and functioning of the female [74] and male reproductive systems [71,75], including the stimulation of androgen release in the testis [76]. In men, THs regulate testicular development and function [75]. Thyroid disorders are associated with gonadal dysfunction, hypogonadism and reduced prostate weight [77,78,79].

THs have long been suspected to be involved in the development of malignancies [80], whereby the maintenance of a hypothyroxinemia was suggested to improve the survival of cancer patients [81]. Whether THs, including T3 and T4, play a role in supporting PCa growth, progression, and metastasis has remained largely unexplored. Albeit, THs influence the development and physiology of the human prostate [82] and the incidence of PCa, as seen from studies using a diet-induced regimen [83]. Epidemiological studies have linked low plasma T3 levels with a low incidence of PCa [84,85] and high T4 levels are significantly associated with an increased risk of any solid cancer, particularly PCa, lung, and breast cancer [84,86]. The latter finding led to the hypothesis that high TH levels correlate with tumor progression [87,88,89,90]. Several case reports have reported a correlation between low TH levels and slower cancer growth [64,91,92,93]. Studies of the availability of T3 for binding to TRβ support a role for T3 and TRβ in PCa. μ-Crystallin (CRYM) sequesters T3 in the cytosol to prevent T3 binding to nuclear TRβ [94], thereby controlling downstream target activation [88]. Our study showed that CRYM and TRβ show reciprocal expression in PCa tissue, whereby low CRYM represents a feature of metastatic PCa [95]. We and others have demonstrated that CRYM expression is deficient in hormone-refractory PCa patients [96,97] indicating reciprocal roles for CRYM and TRβ [98]

The literature is more extensive regarding the specific role of TRβ, perhaps reflecting a more significant role in cancer. TRβ is mainly described as a tumor suppressor [28] because expression is often reduced in human tumors due to deletions and epigenetic modifications [99]. A reduction has been linked to a poor prognosis in hepatocellular, renal, thyroid and breast cancers [100,101,102]. TRβ expression is lost upon chromosomal 3p deletions, especially in breast and liver cancers [64]. In addition to somatic loss-of-function mutations that foster thyroid cancers, there is a high incidence of de novo inactivating TRα and TRβ mutations in hepatocellular, renal, and thyroid cancers [99] which may relate to selection pressures during tumor progression [103]. Loss of TRβ dysregulates several growth control pathways, leading to the exaggerated growth of various cancers [104].

In contrast to a tumor suppressor role for TRβ, TRα/TRβ1 double knockout mice develop fewer skin tumors [105], and enhanced TRβ expression has been detected in colon and head and neck cancers [106,107]. A recent study showed that low cytosolic and enhanced nuclear TRβ levels are indicators of a poor outcome in breast cancer [108], highlighting the importance of distinguishing between cytosolic and nuclear TRβ abundance, as recognised previously from studies of HeLa liver cancer cells [109]. Intriguingly, RXRs seem to have an anti-oncogenic role in PCa [110], providing tentative support to a tumor-promoting action of activated TRβ.

Literature regarding the influence of THs on cancer often presents a view of the clinical implications/morbidity relating to hypothyroidism [84,111,112]. THs stimulate the growth of many cancers, including breast, ovarian, pancreatic, hepatocellular, and renal cancer cells [113,114,115,116]. From in vitro studies, T3 supported the growth of PCa, lung, breast, ovarian and squamous cell cancer cells [64,88,117], and THs have a direct stimulatory effect on some key oncogenic signaling pathways, including the phosphatidylinositol-3-kinase (PI3K)- and extracellular signal-regulated kinase (ERK1/2)-mediated pathways. In vitro studies using the androgen-sensitive LNCaP cells revealed that nmolar T3 stimulated cell growth and the expression of prostate specific antigen [118]. Longterm incubation led to an increased androgen binding capacity in the nucleus of LNCaP cells, suggesting that T3 might induce AR expression ([119,120]. It is known that T3 and androgens act cooperatively to affect prostate specific antigen (PSA) expression [95,118]. However, whether there is a direct interaction between AR and TRβ is unknown.

T3/TRβ driven gene regulation has been analyzed in hepatocellular cancer to identify the proteins involved in tumor progression. In particular, T3-mediated upregulation of expression of the protease furin was seen for hepatoma cell lines, and the investigators concluded that this might enhance tumor metastasis [115,121,122,123]. TRβ has been shown to regulate cell metabolism and tumor-relevant genes. They include the hypoxia-inducible factor 1 subunit α [124], the CD44 stemness factor in the brain [125], cathepsin H (CTSH gene) which is a tumor invasive factor in HepG2 [123], and extracellular matrix proteins ([115]. TRβ has been shown to effect mitochondrial respiration directly [126], which probably contributes to senescence, DNA damage and oxidative stress.

Regarding in vivo studies, upregulation of mRNAs for TRβ together with other NRs and ONRs was observed for a PCa cell xenograft model [127]. Administering 6-n-propyl-2-thiouracil (PTU), a thyreostatic agent, reduced the growth of DU145 and PC-3 xenografts in mice [117] and reduced their growth in hypothyroid mice although enhanced aggressive behaviour of hepatocellular and breast cancer cell xenografts was observed [99].

4.3. Crosstalk between TRβ and Other NRs/Transcription Factors

There is evidence to support the view that there is cross-regulation between THs and the androgen axis and that this occurs in cancer [128] (Figure 3). Exposure of the testes of the Western clawed frog (Silurana tropicalis) to T3 led to increased DHT production, and a low level of androgens in the serum of PCa patients correlated with decreased T3/T4 levels [129]. An androgen/TH interplay was recently observed in the PCa microenvironment to exert a cooperative tumor-promoting effect [130]. However, the above hormonal cross-regulation raises the question of whether the downstream effector NRs – in this case, TRβ and AR – control the same or overlapping gene sets and processes [27]. TRβ/AR crosstalk was shown in silico by detailed promoter analysis of TH- and androgen-dependent genes, which revealed binding sites for both receptors (TRE and ARE sites) in the promoters of AR- and TR-regulated genes, indicating mutual or collaborative gene regulation [131]. Accordingly, TRβ-mediated gene expression is stimulated by both T3 and DHT robustly [132]. Other workers showed that THs increased the expression of AR and androgen synthesis enzymes [133]. These findings were corroborated by a recent transcription factor binding site study that detected an overlap of NRs binding to the same regulatory elements in PCa [134], opening the possibility of a mutual or collaborative TR/AR DNA-binding mode.

There is evidence to support the view that TRs interact with RARs. In 1993, Rosen and colleagues characterized a homologous 20-amino acid region conserved in TRβ, RAR and VDR essential for heterodimerization [135]. They postulated the existence of various heterodimeric combinations to allow for enhanced variability and sensitivity of gene expression regulation. Other early studies also claimed that TRs and RAR form heterodimers, supported by overexpression and subsequent cell-free DNA-binding (EMSAs) and luciferase reporter assays in vitro [59,136,137,138]. Where RARs form heterodimers with TR, they have affinities for consensus and natural HREs like those for TR/RXR heterodimers. Therefore, TR/RAR heterodimers can regulate T3-mediated gene expression [138]. For amphibian limb blastemal and COS transfected cells, ATRA was observed to mediate both RAR- and T3-mediated effects [139]. Stromelysin 3, a vital tissue remodeling protease, was found to be regulated by THs and ATRA due to the presence of both TREs and RAREs in the gene promoter [140]. For rat GH3 pituitary gland cells, ATRA has been shown to antagonize T3 action, presumably at a receptor level [141]. In addition to this complex hormonal crosstalk, T3 stimulation has been shown to regulate the expression of the ATRA synthesizing enzymes within mouse brain cells ([142], underscoring the importance of hormonal crosstalk.

An important recent finding regarding PCa relates to the nuclear corepressor 2/silencing mediator (NCOR2) for RAR and TR. The expression of this corepressor is frequently altered in PCa and other cancers [143,144]. Reduced expression of NCOR2 has been shown to accelerate the failure of androgen deprivation. The investigators used the CWR22 xenograft model to show that a stable reduction of expression of NCOR2 accelerated the recurrence of disease post-ADT [[145].

In parallel to the early TR/RAR interaction studies, Schräder and colleagues showed that VDR might directly interact with TRβ, and that polarity directs gene expression [146,147]. Other workers identified interference by 1,25D3 and ATRA regarding TH regulation of glucocorticoid hormone expression, concluding that VDR-TR and VDR-RAR heterodimers act as competitors of TR-RXR and RAR-RXR complexes [148]. In contrast, others have failed to provide evidence for VDR-TR heterodimerization but showed that both VDR and TR compete for RXR binding [149], still highlighting a crosstalk between both receptors. Support to this view by a study that showed that VDR heterodimerizes with RXR, but not with TRβ [150], and that a delicate balance of ligand availability and the limiting amounts of RXR, which would shift between TR and VDR, would affect the repression versus activation of various genes. Beyond the above findings, reports regarding crosstalk between TR and VDR have been limited. However, a very interesting crosstalk was described for adipocyte [151] whereby TRβ expression was controlled by 1,25D3, and vice versa, and that T3 regulates VDR gene expression in mouse photoreceptors has been reported [152].

There is a crosstalk between TRβ and other NRs. TRβ interacts with ER isoforms, resulting in flexible regulation of the consensus estrogen response element [153], and TRβ interaction with ERα has been shown to regulate mitochondrial activity ([154]. TRβ interacts with PPARγ [155] and is then oncogenic [156]. Crosstalk between TRβ and liver X receptor (LXR) has been identified for lipid metabolism-related genes and other physiological systems such as the central nervous system [157]. Regarding other TFs, TRβ interaction with the Wnt pathway is important based on direct interaction between TRβ and β catenin [158]. Overall, TRβ interaction with the Wnt pathway for several organisms and tissues indicates the promotion of a stem cell phenotype [159]. Other crosstalk includes regarding jun and fos oncogene activities, based on the abilities of TRs to inhibit AP-1 binding to DNA [160]. TRβ mediates repression of STAT5 activity [161], and overactivation of STAT5 signaling has been linked to an oncogenic TRβ variant in breast cancer [162].

Diverse findings bring to attention the complex role that TRβ plays in regulating the physiological status of cells. TRβ interacts with intracellular signalling pathways and with PI3K to play a role in the maturation of mouse hippocampal synapses [163]. There is TH regulation of steroid hormone-associated genes, for example, regulation of the expression of kidney androgen-regulated protein in the developing kidney ([164], and T3 regulation of the expression of androgen receptor-associate protein 70 (ARA70) and sex hormone binding globulin (SHBG) in HepG2 cells [122,165]. TRβ modulates the function of the tumor suppressor p53, leading to differential regulation of p53-regulated genes [153]. Early studies revealed a connection between TR-mediated gene expression and changes to the expression of cell cycle regulators [156,166]. Overexpression of TRβ in thyroid cancer cells led to activation of the RhoB signaling pathway and p21-induced cell-cycle arrest [167].

5. Retinoic Acid Receptors

5.1. The Functionalities of RARs

The three distinct RARs, namely RARα, RARβ, and RARγ are encoded by different genes [168]. In addition, each RAR has isoforms, due to the presence of different promoters, alternative splicing, and use of non-AUG start codons [169,170,171,172]. RARγ is of particular interest regarding a potential new avenue for treating PCa (see later). The central portion of the RARγ protein, which contains the DNA and ligand binding domains, is encoded by seven axons. There are separate N-terminal exons for γ1 and γ2 and a major portion of the gene encodes several exons for untranslated regions of γ1 [173].

ATRA is the natural ligand of RARs and is used to control the transcription of target genes [174,175]. RARs form various heterodimers with RXRα, RXRβ, RXRγ or homodimers and the dimers bind to specific retinoic acid response elements (RAREs) within the promoters of genes. Without ATRA binding to RARs, RAR is associated with RAR/RXR dimers to suppress gene expression due to RAR recruitment of transcription corepressors. ATRA binding to RAR leads to gene expression via the release of corepressors, the recruitment of coactivators [176], and the binding of further factors that include histone acetylase or histone methyltransferases, histone demethylases, and DNA-dependent ATPases [177,178].

A crucial consideration of RARs is whether the main isoforms have distinct roles or whether there is functional redundancy. RARs are required for embryonic development, and double knockouts in mice were needed to observe aberrant phenotypes associated with vitamin A deficiency. In this case, other RARs can perform developmental functions in the absence of a particular RAR [179,180,181]. In contrast, the different patterns of expression of main isoforms and developmental changes within embryo and adult tissues support the view that each has a specific role to normal physiology. RARα expression is ubiquitous within embryonic and adult tissues. In contrast, the expression patterns of RARβ and RARγ within the developing embryo are complex and either tissue-specific or regionalised [182,183]. RARγ mRNA expression within embryonic tissues suggested a role in the development of the central nervous system, and early studies indicated a role for RARβ in the differentiation of adult stratified squamous epithelia [184]. At late stages of zebrafish embryo development, RARγ mRNA is highly restricted to primitive cells, including mesodermal and neural crest stem and progenitor cells, in the head area, in the lateral plate mesoderm, and in the pre-somitic mesoderm of the tail bud [185]. These findings suggested a role for RARγ in early morphogenesis, as also concluded from early findings for mouse embryogenesis [186]. Changes to the levels of expression of isotypes are seen during haematopoiesis. Haematopoietic stem cells and their differentiating offspring express RARα with RARα2 increasing dramatically during myeloid cell differentiation of FDCP mixA4 mouse progenitor cells [187]. In contrast, haematopoietic stem cells and primitive progenitors selectively express RARγ [188].

The distinct roles of RARα and RARγ during haematopoiesis regulate the production of mature blood cells alongside the need to maintain stem cells. Active RARα facilitates cell differentiation whereby ATRA activation of RARα promoted neutrophil differentiation of the human promyeloid cell lines HL60 and NB4 [189,190] and normal myeloid progenitors [191]. These findings led to ATRA differentiation therapy for acute promyelocytic leukaemia, with ATRA together with arsenic trioxide providing a cure for this once fatal disease [192]. Even so, RARα is dispensable to myelopoiesis and instead modulates [193] presumably by influencing the frequency of cell decision-making by myeloid progenitor cells to favour differentiation. In contrast, RARγ is needed for the maintenance/self-renewal of haematopoietic stem cells because numbers were markedly reduced in knockout mice [188]. In keeping with this role, treatment of zebrafish embryos with a RARγ agonist in the absence of exogenous ATRA blocked bone and ganglion development from cranial neural crest stem cells and fin development from mesodermal stem cells and the stem cell populations were maintained. The block of fin development was reversible by washout of the agonist or the subsequent addition of a RARγ antagonist [194].

Findings from molecular studies have supported the view that RARγ controls stem cell behaviour, perhaps by imposing stemness and/or by restricting the propensity of stem cells to differentiate including the temporal and/or spatial onset. RAR/RXR dimers were observed to bind to gene loci within undifferentiated F9 embryonal cells that bind the pluripotency-affiliated transcription factors SOX2, NANOG, and POU5f1 [176]. For embryonic stem cells, RARγ was required for chromatin epigenetic marks and transcription activation [195] and epigenetic reorganisation of the Hoxa and Hoxb gene structures [196]. RAR paralog that is expressed by the annelid worm (Platyneris dumarilli) is interesting in terms of its role in signalling. ATRA transactives the paralog but it binds with a low affinity using a different pocket. Therefore, ancestral RAR is likely to act as a permissive sensor and a suggested role is triggering the spatially restricted onset of neurogenesis. High-affinity RARs have evolved at the base of chordates with an instructive role in regulating the Hox gene cluster, with high affinity being important to sensing complex ATRA gradients [197].

5.2. RARs and Prostate Cancer

ATRA differentiation therapy for acute promyelocytic leukaemia has not extended to PCa nor other cancers [198]. Albeit and from immunohistology studies, increased expression of RARα and RARγ has been reported within high-grade PCa [199]. The LNCaP, PC-3, and DU145 prostate cancer cell lines express RARα and RARγ with LNCaP cells additionally expressing RARβ [200]. However, these cell lines are relatively insensitive to ATRA with the induction of growth arrest and apoptosis requiring a pharmacological amount (2 μM) [200,201].

Whether RARβ plays a role in PCa is uncertain. An association between the methylation status of RARβ2 and PCa risk has been reported [202] and a meta-analysis concluded that RARβ promotor methylation may be a correlate of PCa carcinogenesis. Further studies are needed to demonstrate a prognostic value because different methylation rates have been reported for PCa tissue [203]. That RARβ may play a role in controlling the proliferation of PCa has been argued from the finding that stable transfection of RARβ into the RARβ-negative PC-3 cells led to increased sensitivity to the combined use of a RARβγ-selective agonist (SR11262) and a potent vitamin D3 analogue regarding the inhibition of clonal growth. Increased sensitivity was proportional to the level of RARβ expressed [204].

RARγ expression is of prime importance to regulating the growth of PCa cells for the following reasons. PCa cells seem to have evolved to survive in a low ATRA environment. ATRA levels for patients’ cells were close to the limit of detection (~ 1 ng/g tissue), whereas levels were up to eight times higher in surrounding normal tissue and benign prostate hyperplasia [205]. This is important because nM concentrations transactivated RARγ and 100-fold more was needed to activate RARαα [190,206]. The proliferation of the PCa cell lines LNCaP, DU 145, and PC-3 was stimulated by a level of ATRA that was sufficient to activate RARγ but not RARα (10^-11-10^-9 M), and treatment with 10^-10 M ATRA increased colony formation and the percentage of stem cell-like colonies. The RARγ agonist AGN205327 exerted the same effect as low doses of ATRA [207]. Therefore, the proliferation of PCa cells is highly dependent on the activity of RARγ. Findings from knockdown and knockout studies have provided further support to the view that RARγ promotes cancer cell proliferation, for example, from studies of colorectal and pancreatic cancer cells [208,209].

The activity of RARγ is also important to the survival of PCa cells. Treatment of flask cultures of patients’ cells and the LNCaP, PC-3, and DU145 cell lines with the selective RARγ antagonist AGN205728 was highly effective in driving growth arrest in G1 of cell cycle followed by necroptosis. A concentration of 5 nM AGN205728, close to its ED₅₀ for RARγ of 3 nM, prevented colony formation by the cancer stem cell (CSC)-like cells of the PCa cell lines. AGN205728, therefore, targeted both CSC and non-CSC [207]. Normal prostate epithelial cells and non-neoplastic RWPE-1 cells were significantly less sensitive to the action of AGN205728 than patients’ PCa cells. The use of AGN194310 to antagonise all RARs was as effective as the RARγ selective antagonist against patents’ cells and the PCa cell lines, and normal prostate epithelium cells were less sensitive [200,210,211]. Taken together, the findings support the development of an antagonist of RARγ for use to treat PCa.

RARγ is also an oncogene for various carcinomas [212]. Overexpression related to increased cell proliferation, rapid disease progression, and a poor prognosis has been reported for human colorectal cancer, cholangiocarcinoma, hepatocellular cancer, ovarian cancer, pancreatic ductal adenocarcinoma, renal cell cancer, and high-grade PCa. In keeping, RARγ is an oncogene whose expression is downregulated by miR30a-5p [213] and this tumour suppressor miR is commonly at a low level in cancer cells. Acacetin targeting of the non-genomic actions of RARγ was effective against human hepatocellular cancer cell lines [214] and the specific aldehyde dehydrogenase inhibitors 673A, DIMATE, DEAB, NCT-501, silybin, and solomargine, which interfere with the endogenous synthesis of ATRA, were effective against lung, ovarian, prostate, and uterine cancer cells [212].

From all the above, RARγ regulates the behaviour of multipotent stem/ progenitor cells, whereby agonism blocked the onset of their development. That RARγ is an oncogene and that overexpression within cancer cells correlated with a rapid disease progression and poor prognosis fits well with RARγ, ensuring the stemness of cancer stem cells. These cells are primarily responsible for both aggressive and disease relapse, and their frequency within a tumour varies from very few to up to 27% for melanoma [215]. This significant difference reflects the different types of cancer studied. Still, it may also reflect how well the method used to evaluate cancer stem cells within a tumor had efficiently measured their frequency as argued from studies of myeloma [215]. It is noteworthy that antagonising RARγ killed PCa stem cells and all their offspring within flask-cultured cells, whereby offspring seem to have retained expression of RARγ. Antagonising RARγ did not kill haematopoietic stem cells [190]. Like RARα, the action of RARγ is modulatory rather than obligatory to developmental processes. RARγ2 null mice were normal, and the foetuses of mice null for all RARγ isotypes were visibly normal. The latter mice exhibited growth deficiency, early lethality, and interestingly, prostate squamous metaplasia [216]. Moreover, no adverse effects were seen when mice and rats were given substantial doses of a pan-RAR antagonist (BMS-18945) other than the inhibition of spermatogenesis, which was reversible [217,218]. The use of RAR antagonists seems to be safe in an adult organism. Why the cancer stem cells died by necroptosis when treated with very low doses of the RARγ and pan-RA antagonists is surprising and yet to be resolved.

5.3. Crosstalk between RARs and Other Transcription Factors

In addition to RARs competing with other nuclear receptor superfamily members for binding to RXRs and dimerisation with TR (see above), they crosstalk with AR. RARγ impacts androgen signalling because its expression level influences AR activity. ChIP-seq experiments in PCa cell lines showed that RARγ was bound to active chromatin and significantly overlapped with AR binding. Knockdown of RARγ in LNCaP cells affected the expression of genes associated with the AR response. Further experiments, using the HPr1-AR human prostate epithelial cell line showed that RARγ knockdown resulted in a substantial reduction of the transcriptional response to DHT treatment with known AR target genes affected [219]. RARs crosstalk in other ways as seen for ATRA and membrane receptor-provoked events. In 1990, investigators reported a negative cross-modulation between RARs and the activator protein 1, which regulates gene expression in response to cytokines [220].

β-catenin is particularly interesting regarding crosstalk of RARγ with other TFs. RARγ physically interacts with β-catenin, as shown by co-immunoprecipitation studies. Overexpression in chondrocytes strongly inhibited β-catenin signalling, whereas silencing (RNA-mediated) of endogenous RARγ strongly increased signalling. The investigators proposed that unliganded RARγ would associate with β-catenin to inhibit its signalling [221]. Decreases in β-catenin target gene expression may be relevant to the ability of the RARγ antagonist to kill cancer cells. The interaction between RARγ and β-catenin is more complex because Wnt/β-catenin signalling regulates the expression of Yes-associated protein (YAP) as shown for colon cancer cells [222]. YAP is a coactivator of RARγ and acted via RAREs to reinforce stem cell traits within HT-29 colon cancer cells, including self-renewal. Conversely, the use of the pan-RAR antagonist BMS493 to silence RAR signalling downregulated the stem cell traits of HT29 and 5F31 cells, including their renewal capacity [223]. As seen for RARγ, YAP is an oncogene for several cancers, showing elevated expression in bladder, cervical, colon, gastric, non-small cell lung, oesophageal, and ovarian cancers [224]. In keeping with agonism of RARγ blocking stem cell development, YAP expression in human neural in vitro systems negatively correlated with neuronal differentiation and was seen to promote a neural rest/multipotent phenotype [225].

The role of VDR, like that of RARα, is to promote cell differentiation, and there is crosstalk between the actions of RARα and VDR. Studies of acute myeloid leukaemia cell lines revealed that RARα regulated the expression of a VDR transcriptional variant originating in exon 1a. Un-ligated RARα repressed expression of the VDR gene whereby a high basal level of expression of RARα and a lack of RARα agonism correlated with repressed expression of the VDR gene. Downregulation of the level of RARα expression led to increased VDR gene expression. [226]. Whilst RAR and VDR preferentially bind DNA as heterodimers with RXR, a very early, and a perhaps ignored finding was that VDR-RAR and VDR-RXR heterodimers can act functionally on direct repeat, palindrome, and inverted palindrome response elements [227].

6. Vitamin D Receptor

6.1. The Functionalities of VDRs

The two basic forms of vitamin D are D2 (ergocalciferol) and the main form D3 (cholecalciferol). Vitamin D is not a vitamin because vitamin D3 is made in human skin from 5,7-dehydrocholesterol via a non-enzymatic transformation and upon skin exposed to UV-B radiation [228]. Both forms of vitamin D are not biologically active, requiring conversion to the active forms 1α,25-dihydroxyvitamin D2 and 1,25D3, which have a systemic action like classic steroid hormones.

The composition of the VDR genomic region is very complex and covers ~100 kb located on chromosome 12 [229]. There are 14 exons with multiple enhancers regulating the tissue-specific expression of VDR proteins, with translation spanning from exons 2 to 9 [230,231]. In some individuals, there is a T to C polymorphism, which eliminates the most 5’-located ATG codon in exon 2, and translation is from the second in-frame ATG codon. This means that there are two variants of VDR with lengths of 424 and 427 amino acids [232]. Transcription regulation is complex for the VDR gene region that contains the six exons 1a to 1f because various tissues make alternative use of the exons and their corresponding promoters [230]. Three promoter regions have been identified for exons 1a - 1f; exons 1a and 1d are regulated by the promoter upstream to exon 1a, and exons 1f and 1c have their upstream promoters. How the remaining exons are regulated remains to be elucidated [230,231,232].

There is widespread expression of VDR within tissues. Most of the tissues responsive to 1,25D3 express transcripts originating from exon 1a and 1d. Transcripts that start from exon 1d give rise to a longer VDR protein, named VDR B1 [230,233]. VDR plays a vital role in the endocrine control of calcium-phosphate homeostasis [[234]. A transcript that originates in exon 1f is selectively expressed by tissues that play a role in calcium-phosphate homeostasis [230].

Here, we focus on the capacity of 1,25D3 to drive growth arrest, differentiation, and apoptosis of cancer cells. In this regard, VDR binds to thousands of genomic loci to modulate the expression of hundreds of target genes. VDR, after binding of 1,25D3, forms heterodimers with RXRα, RXRβ, and RXRγ to drive gene expression by modifying chromatin structure. The heterodimers bind to vitamin D response elements (VDREs) within the promotors of target genes (VDRE). VDR also forms homodimers that interact with VDREs. Like RARs, VDR is silent in the absence of ligand due to the recruitment of corepressors. When a ligand is bound, gene expression occurs due to the recruitment of coactivators and eventually RNA polymerase II [235,236]. Secondary/indirect 1,25D target genes are regulated by transcription factors that are encoded by the primary target genes.

6.2. VDR and Prostate Cancer

For over four decades, various studies have considered using 1,25D3 to treat multiple cancers [237]. Laboratory studies showed that 1,25D3 drives the growth arrest and apoptosis of a range of cancer cells, particularly PCa, breast cancer, and leukaemia cells. However, the use of vitamin Ds to treat patients, in general, has been greatly hindered by their hypercalcaemic action because increased blood calcium can lead to soft tissue calcification, increased bone resorption, and can even be fatal [238]. Substantial concentrations of 1,25D3 are often used in in vitro and preclinical studies to achieve growth arrest and apoptosis of cancer cells. A recent appraisal of the literature has brought to attention that the positive outcomes from vitamin D clinical studies do not match up with those from in vitro and preclinical studies, whereby reaching an effective dosage in the clinic is likely to be an issue [239].

From mouse model studies of PCa, the growth of cells and metastasis were faster in mice that were fed a vitamin D3 deficient diet as compared to mice that were given 10,000 IU vitamin D3. Deprivation-mediated acceleration of growth and metastasis was attributed to epithelial to mesenchymal transition [240]. A concern regarding administrating vitamin D3 to increase 1,25D3 levels, or 1,25D3, is that 1,25D3 induces the expression of the 24-hydroxylase CYP24A1 which in turn readily catabilizes 1,25D3. Hence, in a PC-3 prostate xenograft model mice were given 1,25D3 and a CYP24A1 inhibitor which resulted in enhanced inhibition of tumor cell growth [241].

A consensus view is that 1,25D3 is able to drive growth arrest and differentiation followed by apoptosis of many different cancer cell lines. Studies of prostate cancer cell lines show that various anticancer actions have been attributed to 1,25D3. For LNCaP cells, 1,25D3 enhanced apoptosis [242], up- and down- regulated the expression of many genes [243], and inhibited AR signalling [244]. 1,25D3-mediated reported effects on LNCaP, PC-3, and DU145 cells have included decreased invasiveness by the selective modulation of proteases [245] and disruption of glucose metabolism and the tricarboxylic acid cycle [246]. For LNCaP, the non-malignant prostate epithelium cells RWPE-1, and RMPE-2 cells (from RWPE-1 by ki-Ras transformation), an effect of 1,25D3 was to upregulate tumour suppressor miRNAs [247]. Additional 1,25D3 effects on RWPE-1 cells included an antioxidative action and the regulation of pathways such as Wnt, Notch, and NFκB1 [[248, 249]. 1,25D inhibited Wnt activity for patient-derived benign prostate epithelial organoids [250].

There has been a substantial effort to synthesise analogues of 1,25D3 that are more potent than the parent hormone and with a much-reduced calcaemic action [251,252]. In particular, the PRI-1906 analogue has antiproliferative activity against PC-3 PCa cells [253]. As mentioned above, there has been a focus of attention on breast cancer and the analogues PRI-1906, PRI-5201, and PRI-5202 were antiproliferative against human breast cancer cell lines [254,255]. PRI-5105, PRI-5106, and PRI-5202 were effective against human colon cancer cell lines [254,256].

1,25D3 does have effects on PCa, breast, and colon cancer cells, but of fundamental importance is whether any benefit might seen from its use to treat patients. A prime consideration regarding PCa is that the aggressive cell lines are somewhat insensitive to the action of 1,25D3. It has been suggested that this unresponsiveness relates to an elevated nuclear expression of corepressors. In this case, 1,25D3 responsiveness is suppressed by a mechanism involving histone deacetylation, which might be overcome by using histone deacetylase inhibitors [257]. Even so, to date, 1,25D3 and their analogues have not provided an effective adjunct to chemotherapy for prostate cancer regarding a reduction of mortality in clinical trials. Though well-guided trials of vitamin D compounds are limited, there is limited data to support their use to treat or prevent PCa [258]. Whether newer 1,25D3 analogues that are much more potent than the parent hormone and with a negligible calcaemic action can be developed and then used to provide some benefit as an adjunct to chemotherapeutics for PCa and other cancers remains to be seen.

Regarding an interest in the use of vitamin D to prevent PCa, an association has been reported from a meta-analysis between circulating 25-hydroxyvitamin D levels (a measure of vitamin D status) and a reduced risk of PCa [259]. However, this association remains unproven because of the variability of findings from both retrospective and prospective studies [260]. Different outcomes may be related to different levels of vitamin D supplementation. Even so, 12,927 persons received daily 2000 IU vitamin D3 and 12,944 persons received a placebo in the large VITAL trial and there was not a significant reduction in the incidence of all cancers nor of PCa [261,262].

8. Concluding Remarks

The search for effective treatment options for advanced PCa, especially after the cessation of the effectiveness of hormonal therapy, has been ongoing for several decades. Management options have become scarce, the prognosis is poor, and further investigations are needed to overcome advanced disease. NRs are a promising class of signaling-effector targets regarding finding new treatments. Epidemiological and experimental findings affirm that NR signalling contributes to PCa pathogenesis and promotes progression. However, a deeper understanding of the molecular actions of NRs is required to define new diagnostic/prognostic and therapeutic targets. This includes the need to extend information regarding whether and how AR-, TRβ-, RARγ-, and VDR-mediated pathways converge in PCa to co-regulate the expression of critical genes, for example, AR and the proteases kallikrein-related peptidase 3 and transmembrane-serine protease 2. On a mechanistic level, there is a need for a better understanding regarding whether AR, TRβ, RARγ-, and VDR undergo hitherto unknown interactions when having when bound their ligands or relating to the recruitment of cofactors. The emergence of new and compelling omics technologies (ChIPseq, CUT&RUN, CUT&TAG, qPLEX-RIME) enables transcription factor complexes to be determined and the regulated cistromes to be analyzed and compared. From rationales developed from such studies, using combinations of agents that target the actions of NRs may provide new therapeutic approaches to treating androgen-dependent and independent PCa, opening paths to treatments beyond androgen blockers. Drugs that interfere with hormones and RARγ and that activate VDR are well established and might be repurposed for PCa treatment.
