Duan, B.; Mao, L.; Yang, Y.; Feng, Q.; Zhang, X.; Li, H.; Jiao, L.; Zhang, R.; Lu, X.; Chen, G.; Li, C. Preparation of Ti-46Al-8Nb Alloy Ingots beyond Laboratory Scale Based on BaZrO3 Refractory Crucible. Metals2022, 12, 524.
Duan, B.; Mao, L.; Yang, Y.; Feng, Q.; Zhang, X.; Li, H.; Jiao, L.; Zhang, R.; Lu, X.; Chen, G.; Li, C. Preparation of Ti-46Al-8Nb Alloy Ingots beyond Laboratory Scale Based on BaZrO3 Refractory Crucible. Metals 2022, 12, 524.
Duan, B.; Mao, L.; Yang, Y.; Feng, Q.; Zhang, X.; Li, H.; Jiao, L.; Zhang, R.; Lu, X.; Chen, G.; Li, C. Preparation of Ti-46Al-8Nb Alloy Ingots beyond Laboratory Scale Based on BaZrO3 Refractory Crucible. Metals2022, 12, 524.
Duan, B.; Mao, L.; Yang, Y.; Feng, Q.; Zhang, X.; Li, H.; Jiao, L.; Zhang, R.; Lu, X.; Chen, G.; Li, C. Preparation of Ti-46Al-8Nb Alloy Ingots beyond Laboratory Scale Based on BaZrO3 Refractory Crucible. Metals 2022, 12, 524.
Abstract
The high Nb-containing TiAl-based alloy ingot beyond laboratory scale with a composition of Ti-46Al-8Nb (at. %) was prepared by a vacuum induction melting process based on BaZrO3 refractory. An ingot without macroscopic casting defects (such as pipe shrinkage and center line porosity) was finally obtained, and the chemical composition, solidification path, microstructure and tensile properties of the ingots were investigated. The results show that the deviations of Al and Nb content along a 430 mm long central part of the ingot are approximately \mathrm{\pm}0.39 at. % and \mathrm{\pm}0.14 at. %, and the oxygen content in the ingot can be controlled at around 1000 ppm. During the solidification process, the alloy suffered from peritectic reaction and formed columnar grains with anisotropy. In addition to Al segregation and Nb segregation, β-phase particles associated with γ phase at the triple junction of the colonies were observed. Moreover, the mechanical properties of the ingot in the transverse direction are significantly better than those in the longitudinal direction, with a tensile strength of up to high as 700 MPa and a corresponding fracture elongation of 1.1 %.
Chemistry and Materials Science, Metals, Alloys and Metallurgy
