DC-link Current Harmonic Mitigation via Phase-shifting of Carrier Waves in Paralleled Inverter Systems

Version 1 : Received: 12 June 2021 / Approved: 15 June 2021 / Online: 15 June 2021 (14:26:57 CEST)

A peer-reviewed article of this Preprint also exists.

Baburajan, S.; Wang, H.; Kumar, D.; Wang, Q.; Blaabjerg, F. DC-Link Current Harmonic Mitigation via Phase-Shifting of Carrier Waves in Paralleled Inverter Systems. Energies 2021, 14, 4229. Baburajan, S.; Wang, H.; Kumar, D.; Wang, Q.; Blaabjerg, F. DC-Link Current Harmonic Mitigation via Phase-Shifting of Carrier Waves in Paralleled Inverter Systems. Energies 2021, 14, 4229.

Journal reference: Energies 2021, 14, 4229
DOI: 10.3390/en14144229

Abstract

DC-connected parallel inverter systems are gaining popularity in industrial applications. However, such parallel systems generate excess current ripple (harmonics) at the DC-link due to harmonic interactions between the inverters in addition to the harmonics from the PWM switching. These DC-link harmonics cause the failure of fragile components such as DC-link capacitors. This paper proposes an interleaving scheme to minimize the current harmonics induced in the DC-link of such a system. The results show that when the carrier waves of the two inverters are phase-shifted by 90° angle, the maximum high-frequency harmonic ripple cancellation occurs, which reduces the overall RMS value of the DC-capacitor current.The outcome of this proposed solution is a cost-effective DC-harmonics mitigating strategy for the industrial designers to practically configuring multi-inverter systems, even when most of the drives are not operating at rated power levels. Experimental and simulation results presented in this paper verify the effectiveness of the proposed carrier-based phase-shifting scheme for two different configurations of common DC connected multi-converter systems.

Subject Areas

DC-link current; harmonic mitigation; voltage source inverters; multi-converter systems; carrier wave interleaving scheme; DC-grid; phase-shifting; capacitor current ripple; unipolar sinusoidal pulse width modulation
