Total Ankle Replacement Through a Lateral Transfibular Approach in Patients with Ipsilateral Knee Arthrodesis: Report of Two Cases

1. Introduction

Knee arthrodesis is a limb-salvage procedure indicated for patients with a severely damaged, non-reconstructible knee joint, and represents a valid alternative to above-knee amputation (AKA)[1]. Common indications include failed total knee arthroplasty, periarticular tumors, post-traumatic arthritis, and chronic septic arthritis[2]. As a consequence of fusion, knee arthrodesis profoundly alters gait dynamics, typically resulting in a shortened stance phase, a prolonged swing phase, and increased step time on the operated side[3]. Compared with the contralateral non-operated limb, significant differences have been observed in hip, knee, and ankle motion, with compensatory adaptations that increase mechanical stress on adjacent joints during ambulation[2,3,4].

The coexistence of knee pathology and concomitant ipsilateral ankle disorder represents a complex and relatively underexplored topic, with only a few studies addressing their reciprocal biomechanical relationship[5,6,7], mainly focusing on how ankle pathology may influence the knee. However, no reports in the literature describe the reverse scenario, how knee fusion may accentuate or lead to ankle pathology, likely due to the rarity of this condition. To our knowledge, no previous case reports have described the management of ankle osteoarthritis in the setting of ipsilateral knee arthrodesis. Such cases represent a challenging scenario that requires meticulous preoperative planning, tailored surgical techniques, and individualized rehabilitation protocols to achieve optimal lower limb alignment and minimize postoperative complications or the need for reoperation[5].

We present two cases of end-stage post-traumatic ankle osteoarthritis in patients with long-standing ipsilateral knee arthrodesis, both treated with total ankle replacement (TAR) through a lateral transfibular approach.

2. Case Reports

Case One

A 55-year-old woman was referred to our department for evaluation of severe right ankle pain. She was previously known to our service for post-traumatic ankle osteoarthritis, having been assessed three years earlier. At that time, given an acceptable functional reserve, she was managed conservatively with a combination of physical therapy, custom insoles, and anti-inflammatory medications. She now reported progressive worsening of pain over the past six months, which had increasingly limited her walking ability, significantly impaired her daily activities, and necessitated daily pain medication intake (VAS 10). Her past medical history included a giant cell tumor of the proximal right tibia diagnosed 35 years earlier, which was treated with surgical resection and ipsilateral knee arthrodesis using an Ilizarov frame. The disease remained in complete remission following treatment. In 1989, she sustained a right ankle fracture on the same limb, treated conservatively. She had no known comorbidities or history of chronic medical conditions.

At presentation, her weight was 56 kg, height 165 cm, and Body Mass Index (BMI) 20.6 kg/m².

On physical examination, the patient ambulated with the right lower limb held in extension due to the knee arthrodesis and demonstrated an antalgic gait. The ankle was aligned in varus, with reduced stability during single-leg stance. Ankle range of motion was markedly limited, with 15° of fixed equinus and plantarflexion of 20°, and a dorsiflexion deficit resulting from both joint stiffness and partial tibialis anterior insufficiency. The foot demonstrated a cavus morphology. Passive range of motion testing through inversion and eversion of the patient’s foot showed that her subtalar motion was reduced compared to the contralateral side but remained preserved and asymptomatic.

Imaging assessment included conventional bilateral foot and ankle weight-bearing radiographs in anteroposterior, lateral, and Saltzman views (Figure 1), as well as bilateral Weight-Bearing CT (WBCT) scans (Figure 2). Imaging demonstrated advanced right ankle osteoarthritis (Kellgren–Lawrence grade 4[8]) with severe distal tibial bone deformity.

Hindfoot and ankle alignment were fixed in varus and equinus, with an anterior shift of the talus relative to the tibia. Radiographic measurements, are summarized in Table 1.

The patient underwent TAR through a lateral transfibular approach, performed according to the originally described technique[9], using a Zimmer Trabecular Metal™ Total Ankle Replacement (Zimmer TM TAR) implant (size 3 with a size 2 polyethylene insert). The fibula was shortened and stabilized with five 3.5-mm cortical screws. Prophylactic fixation of the medial malleolus was achieved with a single 4.5-mm In2Bones® screw. Additionally, a percutaneous first tarsometatarsal (TMT1) arthrodesis in elevation, according to the Lapidus technique, was performed to correct plantarflexion using an 8 × 40-mm In2Bones® screw. The procedure was carried out under regional anesthesia with sedation, following preoperative antibiotic prophylaxis with cefazolin 2 g.

Postoperatively, the patient was placed in a short-leg cast and instructed to maintain partial weight-bearing for two weeks, progressing to full weight-bearing for an additional two weeks. She was discharged on postoperative day 2 in good general condition. The cast was removed at four weeks, after which a rehabilitation program was initiated, including triceps surae stretching, calf muscle strengthening, and proprioceptive training. Targeted assisted physiokinesitherapy was strongly recommended to emphasize gait re-education, given the challenges posed by the presence of ipsilateral knee arthrodesis.

At the 6-month follow-up, the patient had resumed her normal daily activities. Clinically, she demonstrated a smooth gait compatible with the ipsilateral knee fusion, with the hindfoot and ankle well aligned and stable. Ankle range of motion had improved to 40° of plantarflexion and 10° of dorsiflexion. Imaging confirmed a well-fixed and osseointegrated prosthesis with excellent ankle alignment (Figure 3). Post-operative radiographic measurements are summarized in Table 1. At the 36-month follow-up, imaging showed a stable implant with normal alignment. Clinically, the patient remained asymptomatic and pain-free (VAS 1), with maintained function and gait stability. The patient gave informed consent for the publication of her clinical details and images.

Case Two

A 69-year-old man presented to our department with a 15-year history of progressive left ankle pain. At the time of evaluation, pain was present during weight-bearing, walking, and even at rest (VAS 8). His past medical history included a left ankle fracture in 1996, treated conservatively with casting. In 1972, he sustained an intra-articular fracture of the distal left femur, which was surgically treated but subsequently complicated by chronic osteomyelitis. The therapeutic course was completed in 1976 with a left fibular autograft and ipsilateral knee arthrodesis. He had a history of arterial hypertension, which was currently well controlled with pharmacological therapy.

On examination, he was 168 cm tall, weighed 72 kg, with a BMI of 25.5 kg/m². The ankle was rigid, with limited range of motion (5° dorsiflexion and 10° plantarflexion), and pain localized to the tibiotalar joint during weight-bearing and ambulation. Consistent with his previous fusion, he ambulated with a plantigrade foot but with the knee in extension, and the ankle showed a valgus alignment. Subtalar range of motion was reduced.

Imaging, including bilateral weight-bearing X-rays (Figure 4) and WBCT (Figure 5), demonstrated end-stage tibiotalar osteoarthritis (Kellgren–Lawrence grade 4[8]) with distal tibial and distal fibular bone deformity. The ankle showed a valgus alignment with posterior shift of the talus. Early degenerative changes were also observed in the talonavicular and subtalar joints. The midshaft of the fibula displayed residual deformity from previous surgical procedures. Radiographic measurements are summarized in Table 2. The patient gave informed consent for the publication of his clinical details and images.

The patient underwent TAR through a lateral transfibular approach, carried out according to the originally described technique[9], with implantation of a Zimmer Trabecular Metal™ Total Ankle Replacement (Zimmer TM TAR), size 4 with a size 0 polyethylene insert. The fibula was restored to its appropriate length and stabilized with a single 3.5-mm cortical screw followed by fixation with a six-hole Zimmer ULS plate. The procedure was performed under regional anesthesia with sedation, following administration of preoperative antibiotic prophylaxis with 2 g of cefazolin.

Postoperatively, given the patient’s good bone quality and overall clinical condition, a quick recovery protocol, compared to most postoperative aftercare regimens, was applied[10]. A short-leg cast was placed, and immediate full weight-bearing with crutches was allowed. He was discharged on postoperative day 2 in good general condition. At three weeks, the cast was removed and sutures were taken out, after which a rehabilitation program was initiated, including triceps surae stretching, calf muscle strengthening, proprioceptive training, and hydrotherapy. Considering the concomitant knee arthrodesis, particular attention was devoted to the recovery of a functional and efficient gait pattern, supported by targeted assisted physiokinesitherapy.

The patient was reviewed at 6, 12, 24 and 36 months postoperatively. Clinically, he demonstrated progressive improvement in gait pattern, consistent with his previous knee fusion, and ankle range of motion, achieving a painless 10° dorsiflexion and 30° plantarflexion (VAS 0). Imaging at each follow-up showed a stable implant with correct alignment and no evidence of subsidence (Figure 6). Post-operative radiographic measurements are summarized in Table 2. By the last follow-up, he had returned to his normal daily activities and remained pain-free. The patient gave informed consent for the publication of his clinical details and images.

3. Discussion

The most important finding of this report is that, despite the biomechanical challenges posed by ipsilateral knee arthrodesis, total ankle replacement (TAR) through a lateral approach achieved excellent mid-term clinical and radiographic outcomes. In both patients, TAR allowed restoration of ankle alignment, preservation of residual motion, and recovery of a stable and functional gait compatible with knee fusion. Ankle arthrodesis, the traditional alternative to TAR, was considered suboptimal in these patients, as further rigidifying the lower limb and its restriction of rotational movements would have exacerbated biomechanical limitations, impacting hip kinematics. In patients with a functional knee, part of this rotational demand can be compensated at the knee joint; however, this compensatory mechanism is lost in the presence of knee arthrodesis. Consequently, TAR represents the only viable option for preserving a near-physiological gait pattern in these patients, reinforcing its role as a joint-preserving procedure.

The management of lower limb disorders involving combined deformities at multiple levels (hip, knee, and ankle) remains complex, with heterogeneous and often inconclusive evidence in literature. Knee arthrodesis, in particular, substantially alters gait mechanics and overall lower limb function; indeed, bilateral involvement or pre-existing ipsilateral hip fusion is generally considered a contraindication for knee fusion[2]. According to the same principle, ankle arthrodesis was deemed an unfavorable option in our patients. Some authors have attempted to clarify the biomechanical interplay between these joints through experimental and clinical studies. Naylor et al.[5] investigated the relative influence of the knee and ankle in coronal plane deformity in knee osteoarthritis, highlighting how the hindfoot can compensate for malalignment if healthy, but fails to do so when stiff, particularly during the stance and propulsive phases of gait. Stevens et al.[11] examined pathological lower limb biomechanics in patients with hip pathology, either weak or stiff, and reported a redistribution of power among lower extremity joints with altered ankle mechanics, emphasizing the need to preserve ankle function in this population. Roney et al.[7] analyzed knee kinetics and kinematics in patients with prior ankle replacement or fusion; while no significant clinical differences were found, the study was biased by barefoot gait testing and a small sample size, highlighting the need for larger, long-term investigations.

Reports of concomitant deformity involving multiple lower limb joints are rare. Lesiak[12] described two cases of multi-apical tibial deformity involving both the knee and ankle, treated with a staged approach: initial ankle arthrodesis and tibial osteotomy for realignment, followed by total knee arthroplasty, achieving good clinical and radiological outcomes at 3-year follow-up. Pagenstert and Hintermann[13] reported a case of simultaneous bilateral total knee and TAR, highlighting the advantage of performing all joint replacements in a single session, allowing rehabilitation to be conducted in one phase without the limitation of other arthritic joints. Nozaka[14] presented a case of simultaneous total knee arthroplasty and ankle fusion in a patient with Charcot neuroarthropathy; this strategy proved effective in maintaining leg length and achieving satisfactory alignment.

To our knowledge, this is the first reported mini-series of TAR performed in patients with prior knee arthrodesis, and specifically, the first series describing TAR using a lateral surgical approach. In this scenario, the accuracy of rotational alignment during prosthesis implantation becomes paramount. The decision to employ a lateral transfibular approach and the selected implant type was guided by the intrinsic advantages of this technique. Direct visualization of the ankle’s center of rotation allows optimal correction of both coronal and sagittal alignment and ensures more reproducible positioning of the prosthesis[15]. The fibular osteotomy performed in this approach further facilitates achieving the desired correction. In addition, the lateral approach requires less bone resection, reducing the risk of limb shortening and preserving bone stock for potential revision surgery. Finally, it minimizes the risk of wound complications or neurovascular injury, as it is performed at a distance from the main neurovascular bundle compared with the traditional anterior approach[9]. In both cases, clinical and radiographic outcomes were excellent at mid-term follow-up, consistent with the results reported in the literature about this type of implant[16,17].

This report has several limitations. First, the number of cases is limited, preventing any generalization of the results. Second, no functional scores or formal gait analysis were performed, which would have provided objective measures of functional recovery. Finally, although follow-up reached 3 years, this period is still relatively short to draw definitive conclusions regarding long-term implant survival and functional outcomes.

Nevertheless, the main strength of this report lies in being, to our knowledge, the first description of total ankle replacement performed in patients with ipsilateral knee arthrodesis and the first to report the use of this specific prosthetic implant in such a setting. These cases contribute original information regarding the feasibility and technical considerations of TAR in a rare and biomechanically demanding condition. From a clinical perspective, preserving ankle motion appears particularly relevant when knee mobility is absent, as the compensatory capacity of the lower limb is inherently reduced. In this context, TAR may be considered a joint-preserving strategy, provided that careful preoperative planning, accurate restoration of coronal, sagittal, and rotational alignment, and a rehabilitation program focused on gait re-education are implemented.

4. Conclusions

Total ankle replacements through a lateral transfibular approach can be a viable option for the management of end-stage ankle osteoarthritis in patients with ipsilateral knee arthrodesis, offering the benefit of motion preservation and satisfactory clinical and radiological outcomes when meticulous surgical planning and tailored rehabilitation are applied.
