Kasap, S.; Wächter, E.W.; Zhai, X.; Ehsan, S.; McDonald-Maier, K. Novel Lockstep Technique with Roll-back and Roll-forward Recovery to Mitigate Radiation-Induced Soft Errors. Preprints2020, 2020060055
Kasap, S.; Wächter, E.W.; Zhai, X.; Ehsan, S.; McDonald-Maier, K. Novel Lockstep Technique with Roll-back and Roll-forward Recovery to Mitigate Radiation-Induced Soft Errors. Preprints 2020, 2020060055
Kasap, S.; Wächter, E.W.; Zhai, X.; Ehsan, S.; McDonald-Maier, K. Novel Lockstep Technique with Roll-back and Roll-forward Recovery to Mitigate Radiation-Induced Soft Errors. Preprints2020, 2020060055
APA Style
Kasap, S., Wächter, E.W., Zhai, X., Ehsan, S., & McDonald-Maier, K. (2020). Novel Lockstep Technique with Roll-back and Roll-forward Recovery to Mitigate Radiation-Induced Soft Errors. Preprints. https://doi.org/
Chicago/Turabian Style
Kasap, S., Shoaib Ehsan and Klaus McDonald-Maier. 2020 "Novel Lockstep Technique with Roll-back and Roll-forward Recovery to Mitigate Radiation-Induced Soft Errors" Preprints. https://doi.org/
Abstract
An attractive choice for implementing radiation applications is to deploy All-Programmable System-on-Chips (APSoCs) due to their high-performance computing and power efficiency merits. Despite APSoC's advantages, like any other electronic computer, they are prone to radiation effects. Processors found in APSoCs must, therefore, be adequately hardened against ionizing-radiation to become a viable alternative for harsh environments. This paper proposes a triple-core lockstep (TCLS) approach to secure the Xilinx Zynq-7000 APSoC dual-core ARM Cortex-A9 processor against radiation-induced soft errors by coupling it with a MicroBlaze TMR subsystem in Zynq's programmable logic (PL) layer. The proposed strategy uses software-level checkpointing principles along with roll-back and roll-forward mechanisms (i.e. software redundancy), and hardware-level processor replication as well as checker circuits (i.e. hardware redundancy). Results of fault injection experiments show that the proposed solution achieved high soft error security by mitigating about 99\% of bit-flips injected into both ARM cores' register data.
Engineering, Electrical and Electronic Engineering
