Intracranial Hemorrhage After Reduction Malarplasty: A Review Focusing on Surgical Technique

1. Introduction

Each year, thousands of patients undergo reduction malarplasty (RMP) in East Asia. Several complications associated with RMP have been reported. In an analysis of 14 articles including 3,149 RMP cases, Myung et al. [1] reported complications such as transient sensory weakness (5.5%), drooping (2.8%), nonunion (2.2%), asymmetry (1.8%), restricted mouth opening (1.8%), uncontrollable bleeding (1.3%), and facial nerve injury (0.9%). According to their report [1], the overall complication rates associated with RMP were relatively low. Plastic surgeons have provided detailed descriptions of complications that occur after RMP [2]. These include facial asymmetry, facial sagging, inferior displacement of the zygoma, scarring alopecia, hyperostosis of the cheekbones, loosening of bony fixation, temporomandibular joint movement restriction, localized contour depression and irregularity, and osteolysis or resorption of the cheekbone. However, plastic surgeons may have limited awareness of intracranial hemorrhage following RMP, and relatively little attention has been given to this complication. Moreover, intracranial hemorrhage can result in serious neurological sequelae [3,4,5].

A thorough understanding of surgical anatomy and operative technique is essential to reduce complications after RMP. In this review, I examine several RMP techniques and describe the occurrence and prevention of this serious complication through a detailed analysis of intracranial hemorrhage following RMP.

2. Association Between Intracranial Hemorrhage and RMP

There is a paucity of studies focusing on intracranial hemorrhage as a complication of this procedure. To the best of my knowledge, only three reports of intracranial hemorrhage after RMP have been published [3,4,5]. Kim et al. [3] reported an intracerebral hemorrhage in the temporal lobe caused by penetration of a reciprocating saw during RMP performed via the intraoral approach. Yim et al. [5] reported an epidural hemorrhage resulting from injury to the middle meningeal artery during RMP via the intraoral approach. Both reports are not indexed in the PubMed database but can be identified through Google Scholar (https://scholar.google.com). The full text of Kim et al. [3] is available in Google Scholar; however, the article is written in Korean, with only the abstract and figure captions provided in English. The full text of Yim et al. [5] is written in English but is available only through the Airiti Library (airitilibrary.com). Lee et al. [4] described a case of subdural and subarachnoid hemorrhage after RMP; however, detailed clinical information regarding this complication was not provided. Intracranial hemorrhage after RMP is rare, and the limited number of published cases makes comprehensive analysis challenging. Therefore, in this review, I describe the occurrence and prevention of this serious complication through a detailed analysis of intracranial hemorrhage following RMP, with particular emphasis on surgical technique.

3. Association Between the Coronal Approach to RMP and Intracranial Hemorrhage

Several operative techniques for RMP have been described. The two major surgical approaches are the coronal and intraoral incisions [6,7,8]. In RMP, the choice of surgical technique by the plastic surgeon depends on three factors: patient preferences, the degree of zygomatic prominence, and the surgeon’s skill level [2]. The coronal approach provides a much wider operative field, enabling accurate cutting, and fixation of the malar complex. In contrast, the intraoral approach is more widely used because the longer incision required for the coronal approach is associated with prolonged operative time and a longer scalp scar. Furthermore, some patients decline a long scalp incision [9].

Zhang et al. [2] reported biomechanical changes in the zygomaticus and masseter muscles, as well as related complications, according to three RMP techniques. These considerations are important when plastic surgeons select a surgical method. However, intracranial complications should also be taken into account. The two reported cases of intracranial hemorrhage [3,5] occurred after RMP performed via the intraoral approach. The case reported by Lee et al. [4] did not include a detailed description of the surgical technique used. Based on these reports, intracranial hemorrhage related to surgical manipulation appears more likely to occur after the intraoral approach than after the coronal approach.

The coronal approach offers advantages for precise osteotomy because it provides a wide operative field for fixation of the malar complex [9,10]. RMP using the coronal approach is performed as follows [7,10]. An “M”-shaped scalp incision is made approximately 10 cm posterior to the hairline. Dissection in the temporal area is performed along the subtemporoparietal fascial plane. After identification of the bony margins of the zygomatic arch and body, the zygoma is fully exposed through subperiosteal dissection. The insertions of the temporalis fascia and the masseter muscle to the malar complex are preserved, except at the osteotomy sites. Medial (zygomatic body) and lateral (zygomatic arch near the articular tubercle) malar osteotomies are performed to mobilize the malar complex. The zygomatic arch near the articular tubercle is cut obliquely from posterior to anterior. RMP using the coronal approach allows accurate osteotomy and precise reduction of the maxillary bone within a wide surgical field. Therefore, this approach carries a very low risk of intracranial hemorrhage related to surgical manipulation for two reasons. First, the wide surgical field permits visualization of the full thickness of bone at the osteotomy site. Second, the tip of the reciprocating saw is oriented toward the facial surface rather than toward the cranial cavity, as shown in the Figure 1. As long as the saw blade is aligned along the proper axis and direction, there is no risk of penetrating the intracranial cavity or skull.

4. RMP via the Intraoral Approach

For malar repositioning, a coronal incision has been proposed to allow accurate reconfiguration of the bone in its intended position. However, the coronal approach requires extensive dissection and is therefore more time-consuming than intraoral and preauricular incisions [11]. Consequently, various techniques for RMP have been introduced, including L-shaped osteotomy via the intraoral approach, limited preauricular incisional access, zygomatic arch reduction through multiple osteotomies, rotational techniques, facelift with malar repositioning, and boomerang osteotomy [12,13,14,15,16,17,18].

The intraoral incision alone, or in combination with preauricular and temporal

incisions, is most commonly used because of its simplicity, strong fixation, and ability to achieve the desired degree of zygomatic reduction [15]. However, this approach is associated with several complications, including infraorbital nerve paresthesia, difficulty in creating symmetrical shapes, a limited maximum reduction volume occasionally resulting in under-correction, and cheek ptosis caused by extensive detachment of the masseter and zygomaticus major muscle insertions. Moreover, the intraoral approach is associated with additional technical challenges, such as difficult osteotomy and fixation due to limited exposure. The narrow operative field inherent to this approach makes it difficult to achieve a precise extent of osteotomy [9].

(1)

Lateral osteotomy of the zygomatic arch near the articular tubercleIntraoral approach alone

The lateral osteotomy line of the zygomatic arch near the articular tubercle is created either as a greenstick fracture or as a full-thickness fracture via the intraoral approach [2,19,20]. The osteotomy of the zygomatic arch is performed posteromedially, approximately 1 cm anterior to the articular tubercle [19]. When the intraoral approach alone is used, osteotomy of the zygomatic arch near the articular tubercle poses little risk of skull fracture because the cranial bone in this region is relatively thick (Figure 2).

Minimal separate incision in the sideburn area

Ma et al. [18] and Cho [7] described another technique (Figure 3). A minimal separate incision is made in the sideburn area. The root of the zygomatic arch is exposed through dissection and then fractured with a small osteotome just anterior to the articular tubercle. Lee and Lee [21] presented a video demonstrating arch osteotomy using a preauricular incision. With this separate sideburn incision technique, osteotomy of the zygomatic arch is unlikely to cause skull base injury.

(2)

Medial osteotomy

L-shaped osteotomy of the zygomatic body

An osteotomy of the zygomatic body performed via the intraoral approach carries a potential risk of injury to the middle cranial fossa. Wang et al. [22] described RMP using an L-shaped osteotomy of the zygomatic body (Figure 4). The degree of reduction is determined by the amount of bone removed between two parallel vertical osteotomy lines. An oblique osteotomy is made in the upper portion of the zygoma, approximately 5 mm inferior to the inferolateral margin of the orbit. Ma et al. [18] and Zhang et al. [2] also described RMP using an L-shaped osteotomy of the zygomatic body via the intraoral approach. In these techniques, two parallel vertical osteotomy lines are created on the anterior aspect of the zygomatic bone, near the inferior border of the zygomaticomaxillary suture. A horizontal osteotomy is then made from the lateral portion of the zygomaticofrontal suture toward the two vertical osteotomy lines [2,18]. Lee and Lee [21] presented an operative video demonstrating the L-shaped osteotomy of the zygomatic body. As shown in Video 2 [21], the tip of the reciprocating saw is not visible during osteotomy of the zygomatic body because of the narrow surgical field.

When performing an L-shaped osteotomy of the zygomatic body using a reciprocating saw or chisel, the vertical osteotomy does not pose a risk of skull base injury. Instead, it carries a potential risk of maxillary fracture. In contrast, during the horizontal osteotomy, the tip of the reciprocating saw may injure the middle cranial fossa.

Linear osteotomy of thezygomatic body

Lee et al. [20] and Zhang et al. [2] described a linear osteotomy of the zygomatic body. The medial osteotomy line is placed along the anterior border of the inner cortex of the zygomatic arch, approximately 0.5 cm posterior to the anterior border of the masseter attachment to the zygomatic bone. This medial osteotomy may injure the middle cranial fossa. Performing the osteotomy in this direction positions the tip of the reciprocating saw very close to the middle cranial fossa, thereby increasing the risk of skull base injury (Figure 5).

Both intracranial hemorrhages reported by Kim et al. [3] and Yim et al. [5] may have resulted from injury to the middle cranial fossa during medial osteotomy of the zygomatic body. Blind manipulation in the deep portion of the zygoma via the intraoral approach, together with deep insertion of the reciprocating saw, may lead to injury of the middle cranial fossa. Because osteotomy in this region is performed without direct visualization, the surgeon’s experience is critical. The risk of these complications may be reduced if the surgeon accurately recognizes the position of the reciprocating saw tip through surgical experience and a thorough understanding of anatomical landmarks. In particular, when performing osteotomy at the zygomatic body, it should be recognized that the reciprocating saw in a linear osteotomy is positioned closer to the skull base than in an L-shaped osteotomy.

5. Possible Mechanisms of Intracranial Hemorrhage in the Reported Cases

Yim et al. [5] proposed two mechanisms for epidural hemorrhage after RMP performed via the intraoral approach. The first mechanism involves inappropriate manipulation of a reciprocating saw and other instruments during medial osteotomy of the zygomatic arch. The second mechanism suggests that force applied to the temporal bone and bony spicules while elevating the fractured zygomatic arch may result in tearing of the middle meningeal artery. The former mechanism appears to be the more plausible explanation for epidural hemorrhage secondary to middle meningeal artery injury. Elevation of both the zygomatic body and arch is unlikely to transmit sufficient force to the middle cranial fossa, through which the middle meningeal artery passes. Instead, such elevation would more likely cause injury to the orbit or sphenoid bone. In Figure 1 of Yim et al.’s report [5], no apparent injury to the orbit or sphenoid bone on the left side of the skull is observed.

Kim et al. [3] reported that a temporal lobe hematoma developed following aggres sive instrument manipulation (Figure 6). During craniotomy for evacuation of the intracranial hemorrhage, a dural defect in the middle cranial fossa, a skull base bony defect, and a bony fragment within the intracranial cavity were identified (Figure 7). Kim et al. [3] suggested that the osteotomy procedure of the zygomatic body may have resulted in intracerebral hemorrhage.

However, Yim et al. [5] and Kim et al. [3] did not describe the detailed surgical technique used for RMP. During osteotomy of the zygomatic body, excessive insertion of the reciprocating saw may result in injury to the middle cranial fossa (Figure 6), followed by the development of epidural or intracerebral hemorrhage. Lee et al. [4] also reported subdural and subarachnoid hemorrhage in a 24-year-old female patient after RMP and submental liposuction. The patient subsequently progressed to brain death. Although imaging and autopsy findings were not available, the mechanism of cerebral hemorrhage in this case is presumed to be similar to that in the two previously described cases. Spontaneous subdural and subarachnoid hemorrhage are rare in young patients without coagulation disorders or other underlying diseases.

Preoperative measurement of the distance between the zygomatic body and the middle cranial fossa using three-dimensional computed tomography may help prevent such complications. When using a reciprocating saw via the intraoral approach, if the tip is perceived to contact bone unexpectedly, the surgeon should immediately discontinue use of the saw and reassess the anatomical position.

6. Surgical Treatment of Intracranial Hemorrhage After RMP

Intracranial hemorrhage occurring after RMP performed via the intraoral approach may present as an epidural hemorrhage originating from the middle cranial fossa, an intracerebral hemorrhage in the temporal lobe, or a subdural hemorrhage. In such cases, surgical management for hematoma evacuation is similar to that for cerebral hemorrhage caused by other forms of trauma. Craniotomy is required for the following reasons. When stereotactic evacuation of an intracerebral hemorrhage is attempted through a burr hole, there is a risk of rebleeding and inadequate hemorrhage control. In addition, craniotomy is mandatory in cases of epidural or subdural hemorrhage. Although the RMP procedure is performed intraorally, the risk of ascending infection is low. If a dural defect is identified in the middle cranial fossa, cerebrospinal fluid leakage may occur. Therefore, repair of the dural defect is necessary using tissue adhesives such as Greenplast (Greenplast, GC Biopharma, Yongin-si, Republic of Korea), artificial dura mater, or autologous fascia.

Sequelae were reported in all three cases [3,4,5] described in the literature, and one of three case resulted in death. Therefore, preventive measures to avoid intracranial hemorrhage are of paramount importance.

7. Conclusions

Each surgical technique in RMP has distinct advantages and disadvantages. The conventional coronal approach is unlikely to cause intracranial hemorrhage because the orientation of the reciprocating saw does not place the skull base at risk. In contrast, when performing osteotomy of the zygomatic body via the intraoral approach, there is a risk of injury to the middle cranial fossa by the tip of the reciprocating saw, particularly when the saw is inserted excessively deeply during osteotomy of the malar complex.
