Clinical Electrophysiology and Mathematical Modeling for Precision Diagnosis of Infertility

1. Introduction

Despite the cellular heterogeneity within the testis, Sertoli, Leydig, peritubular and germ cells can function independently, according to their specific roles, while also cooperating dynamically through intacrine, paracrine and/or autocrine actions. This guarantees spermatogenesis and steroidogenesis under the control of gonadotrophins, androgens and several factors locally produced, such as estrogens [1]. Steroidogenesis in the testis occurs mainly in the Leydig cells, particularly the synthesis of testosterone, which can be irreversibly converted into estradiol in the Sertoli cells by a protein complex of cytochrome P450 aromatase [1,2].

The spermatogenesis wave is influenced by different factors, such as hormonal, environmental, and nutritional factors, as well as genetic and epigenetic diseases [2,3]. The main physiological role of the somatic Sertoli cells is to maintain spermatogenesis through the blood-testis barrier by providing the mechanical and nutritional support to neighboring germ cells, in order to create a suitable immunological and endocrine microenvironment [3]. Therefore, the number and health of the Sertoli cells at the prepubertal stage is determinant for spermatozoa production to guarantee fertility throughout adult life [3,4,5,6]. The secretory activity of Sertoli cells relies on ionic changes that are triggered by voltage-dependent calcium channel, potassium channel and chloride channel activities to promote exocytosis of a fluid rich in ions, nutrients, proteins and growth hormones to germ cells to support the progression of the spermatogenic wave [7,8].

2. Electrophysiology and Mathematical Models

Electrophysiology is a definitive and powerful approach for investigating ionic channel-related diseases with high precision and celerity. This methodology offers the possibility of recording the electrical behavior of cells through a diversity of technical conformations within recording modes, such as intracellular recording and patch clamp techniques (cell attached, whole cell, excised path), to provide unprecedented insights into cellular activity [9,10]. One of the properties of electrophysiology recordings is signal processing and recording at high speed and in real time for a variety of linear and non-linear operations. These recordings can accurately translate the channel activity that is related to a critical cell function in health or disease [11,12,13]. The membrane potential is a physical chemical variable that may trigger cell activation processes, resulting in secretion (exocytosis), plasma membrane protein activation (opening/closing ionic channel), cell contraction (cytoskeleton), pump and plasma membrane enzyme activation. With reference to these parameters, key data were selected to explore the hormonal regulation of Sertoli cell secretion during the determinant window of testis maturation, at the pre-pubertal and pubertal phases [5].

Mathematical analysis represents an important tool for unraveling mechanisms that drive biological systems and can be applied to electrophysiology, using the patch clamp method, to obtain the curves used in theoretical models [14]. The mathematical model for predicting signals, caused by conformational changes in ionic channels, due to changes in ionic permeabilities, cellular ATP and other quantities, is of great importance for understanding cellular behavior in the presence of thyroid hormones, FSH, and testosterone, among others [15].

3. Follicle-Stimulating Hormone Alters the Plasma Membrane Potential in Sertoli Cells

Follicle-Stimulating Hormone (FSH) is a glycoprotein, secreted by adenohypophysis, that binds to a pleiotropic receptor in the testis, exclusively at plasma membrane of Sertoli cells [6]. The signal transduction of FSH relies on the genomic responses for Sertoli cell proliferation and maintenance, differentiation and apoptosis of spermatogonia. Furthermore, FSH plays a central role in the development and function of the testis via cAMP/PKA, PI3K/Akt, ERK/MAPK signaling for genomic responses [16,17,18,19]. Sertoli cells exhibit a fine diversity of electrophysiological properties, depending on the phase of testicular maturation, the activity of the spermatogenic wave, and the influence of the hormonal or chemical environment. FSH also exhibits a complementary and efficient route of signal transduction, known as non-classical or rapid response pathways. As such, electrophysiological recordings demonstrate that FSH produces immediate hyperpolarization, followed by depolarization, in Sertoli cells in the seminiferous tubules of the immature rat testis [9]. One of the intracellular pathways through which FSH influences ionic homeostasis is via the opening or closing of plasma membrane ionic channels in the Sertoli cells, which can alter the intracellular ionic calcium concentration to activate a number of cellular functions, such as exocytosis [9]. The advantage of using this technique for such observations was its ability to precisely delineate the ionic mechanism coordinated by FSH (rapid responses/seconds) during amino acid transport. This mechanism is independent to those mediated by the serpentine receptors coupled to G-proteins in the plasma membrane, making this a valuable tool for studying the amino acid-related diseases associated with male infertility [20]. However, this raises the question as to how this model aligns with human physiology? To complement these studies, with the popularization of mathematical modeling software, we developed the first mathematical model for potassium channel activity, based on recordings of electrical currents induced by K⁺ efflux in voltage-sensitive potassium, K_v (the currents responsible for rapid responses in Sertoli cells), obtained using the patch clamp method [15]. This model determined the membrane potential changes following the administration of the FSH hormone in the cell and demonstrated great similarity with the in vitro electrophysiological recordings obtained by Wassermann et al [9]. The model uses potassium channel currents to obtain the equations demonstrated in the Hodgkin & Huxley model, in 1952 [21]. The membrane potential changes caused by hormones produce an electrical stimulus input for the H-H model. Such changes are caused by the ATP-dependent Na⁺/K⁺ pump, which can be modeled by several methods. In this model, the equations of the Na⁺/ K⁺ enzymatic model described by Hernandez et al. [22] were applied to determine the relationship between the Na⁺/K⁺ pump and the membrane potential. Variations in hormone concentration administered to the cell caused changes in the ATP-dependent Na⁺/K⁺ pump current, opening the Kv channels.

Additionally, techniques such as those that use radiolabeled compounds, e.g. [1-¹⁴C]MeAIB and ⁴⁵Ca²⁺ influx, associated with electrophysiology, have been able to characterize a plasma membrane target for FSH on amino acid transporters and calcium channels, signifying an important discovery related to hormonal rapid responses [9,23]. As such, this profile of multimodal electrophysiology can improve precision medicine approaches and be used to suggest molecular structures that interact perfectly with a therapeutic target.

4. Thyroid Hormones Act on Sertoli Cells by Activating Potassium Channels

Thyroid hormones, such as thyroxine (T₄), 3,5,3’-L-triiodothyronine (T₃), 3,3’,5’-triiodothyronine (rT₃), and even the metabolite of rT₃, O-(4-hydroxyphenyl)-3-3’-diiodo-L-tyrosine (T₂), have defined roles in the testis, depending on the phase of testicular development. These hormones are critical during the postnatal period before the formation of the blood-testis barrier [24].

In the mid-1990s, following the discovery of various thyroid receptor isoforms, interest grew in the nongenomic effects of thyroid hormones, mediated by cell surface-receptors [25]. Using intracellular recordings, our laboratory reported that T₃ and T₄ act directly at the plasma membrane on amino acid accumulation and induce immediate hyperpolarization, mediated by potassium and calcium channels, in intact Sertoli cells in seminiferous tubules. In addition, the intracellular recording technique allowed us to distinguish the genomic and nongenomic effects of both of these thyroid hormones in Sertoli cells [26,27,28]. The actions of thyroid hormones in Sertoli cells are also characterized by the absence of nuclear receptor activation, and are rather mediated by membrane-initiated mechanisms, known as non-classical hormone-binding elements, at the plasma membrane. In the whole immature rat testis, thyroxine interacts with the plasma membrane of Sertoli cells, opening potassium channels (K⁺-ATP and K⁺-Ca²⁺) and calcium-dependent chloride channels (Cl^--Ca²⁺), and hyperpolarizing the cells. This hyperpolarization triggers the opening of voltage-dependent Ca²⁺ channels, Ca²⁺ influxes and depolarization, which then stimulates Na⁺-amino acid co-transport. Additionally, transient modulations in cytosolic Ca²⁺ involve protein kinase (PK) C, a pivotal protein that may regulate phosphorylation of plasma membrane ionic channels and/or support cross-talk with gene transcription [7,29]. In addition, the T₄ integrin plasma membrane receptor activates amino acid uptake, but does not mediate the calcium influx, cell secretion or the nuclear effects of the hormone.

As such, these data suggest that the physiological responses of Sertoli cells to thyroid hormones are dependent upon continuous cross-talk for different signal transduction pathways to be accomplished. In the case of rT₃, this molecule triggers rapid responses such as calcium influx and exocytosis, mediated by integrin receptors in the Sertoli cells. This suggests that different thyroid hormone metabolites act on specific binding sites at plasma membrane to start a distinct responses [30,31]. Building on these data, the new ionic target of rT₃ at the plasma membrane of Sertoli cells was precisely identified by electrophysiology using whole-cell patch-clamp techniques. Findings showed that rT₃-induced calcium influx involves potassium efflux and selective activation of ionic calcium channels, and the Na⁺/K⁺ ATPase pump, all occurring within less than 5 minutes. These explicit nongenomic responses effectively coordinate exocytosis. Studies on T₂ also merit attention, as its metabolite demonstrates a stimulatory effect on calcium influx in immature rat Sertoli cells. Given the very low concentrations of T₂ (10^-15 and 10^-12 M) and the immediate maximum response (30 seconds), we conclude that its effect is plausible, as T₂ is the final metabolite to be inactivated [10,30].

5. The Influence of Retinol on Calcium and Potassium Channels in Sertoli Cells

Retinol plays a known role in testicular functions by influencing spermatogenic processes. Excess retinol can cause spermatogenic lesions, while deficiency interrupts the ongoing spermatogenic wave and reduces cell secretion. Retinoids can act on Sertoli cells, germ cells and Leydig cells, modifying the secretory activity of Sertoli cell functions, disturbing secretory activity and decreasing cell proliferation and differentiation [31,32,33,34]. The rapid responses, or non-classical mechanism of action, of retinol in the Sertoli cells of immature rat testes was first reported in 1990’s by Loss and colleagues [35]. Authors demonstrated that the plasma membrane action of retinol in Sertoli cells was mediated by voltage-dependent calcium channels to regulate calcium influx and amino acid uptake. The classical intracellular recording showed an immediate oscillatory membrane potential response, followed by a significant reduction in membrane potential. These events were associated with calcium influx and amino acid uptake [35,36,37].

With regard to the vitamin A endocrine system, we demonstrated, using the patch-clamp technique, that retinol increased voltage-dependent potassium currents (Kv) in Sertoli cells. The inhibition of these responses by tetraethylammonium (TEA) confirmed a role for TEA-sensitive K⁺ channels in these effects. Additionally, using precise patch-clamp techniques, we reported, for the first time, cross-talk between retinol and testosterone, as well as depolarization and activation of repolarization by K_v currents in Sertoli cells [37]. These ionic modulations play a physiological role in Sertoli cells, spermatogenesis and male fertility via stimulation of secretory activities.

6. Testosterone Modulates Electrical Activities in Sertoli Cells

Using intracellular recording with the standard single microelectrode technique, the roles of epitestosterone and testosterone in both the proliferative and non-proliferative phases of Sertoli cells were found to be similar, but independent of the classical androgen receptor. In addition, epitestosterone, an 17α-epimer of testosterone, exhibits a rapid response that involves calcium and depolarization of Sertoli cells. Similar data were also obtained when recordings were carried out in ex vivo intact seminiferous tubules from the immature rat testis. In this case, electrophysiology served as useful tool to separate the plasma membrane effects of epitestosterone and testosterone from their genomic responses, which are mediated by classic androgen receptors [38].

Another advantage of using this technique is that it takes into consideration the fine architecture of Sertoli cells. The plasma membranes of Sertoli cells cover, or are the scaffolding of, seminiferous tubules. As described in the literature, Loss et al. [35] standardized a protocol for recording the membrane potential of Sertoli cells by crossing over the plasma membrane of myoid peritubular cells within enriched seminiferous tubules Data collected from ex vivo and intact seminiferous tubules demonstrated a similar resting potential to that found in SCE seminiferous tubules [38], where SCE refers to testes without germ cells after embryos have been irradiated in utero with 1 gray of ⁶⁰Co, between 19 – 21 days of pregnancy.

In another electrophysiological recording conformation, whole-cell electrophysiology showed that both testosterone and retinol increased voltage-dependent potassium potassium currents (Kv) in isolated Sertoli cells. These novel data suggested the occurrence of crosstalk between retinol and testosterone, triggered by a rapid response mediated by voltage-dependent calcium channels, and culminating in a depolarization followed by repolarization of Sertoli cells, thereby contributing to exocytosis and guaranteeing male fertility [37].

7. 1,α25(. OH)₂ Vitamin D₃Activates Chloride Channels and Exocytosis in Sertoli Cells

The active form of vitamin D, 1α,25(OH)₂ Vitamin D₃ (1,25-D₃), is a secosteroid hormone that affects biological functions in the organism, such as calcium and phosphate homeostasis, as well as the expression of proteins such as calcium-binding protein (CaBP), by non-genomic responses and genomic responses, respectively [39].The testis is one of 38 tissue types in which the vitamin D receptor (VDR) is expressed, and it also is expressed in Sertoli and germ cells [40]. The hormonal regulation of fluid and protein secretion by Sertoli cells is critical throughout the spermatogenic wave and involves ionic channel modulation. Surprisingly, 1,25-D₃ is reported to trigger the activation of chloride channels in the Sertoli cell line, TM4, characterizing the precise regulation of the electrochemical gradient during the exocytosis process [8,40,41]. In Sertoli cells, the high K⁺ causes a strong depolarization, followed by a repolarization, caused by K⁺ efflux, which is mediated by the activation of voltage-dependent K⁺ channels. In response to 1,25-D₃, within 10 min of exposure, the efflux of K⁺ was blocked by TEA, an inhibitor of voltage-dependent K⁺-channels, indicating that secretory activity and repolarization of Sertoli cells occurred through the Ca²⁺ conventional exocytosis pathway. Although several channels orchestrate the stimulus for Sertoli cell secretion, the recovery of membrane potential is coordinated by different and select K⁺ ionic channels, such as ATP-dependent K⁺ channels, voltage-dependent K⁺ channels and Ca²⁺-dependent K⁺ channels. Based on the precise measurement of ionic channel activity in the presence of 1,25-D₃, we demonstrated, for the first time, the non-genomic action of this hormone in primary cultures of Sertoli cells from immature rat testis, which was mediated by K⁺-current potentiation coupled to exocytosis. This effect suggests the occurrence of a Ca²⁺ influx, followed by K⁺ efflux, and repolarization, characterizing a functional role for 1,25-D₃ in male fertility, via stimulation of cell secretion.
