Effect of Film Thickness on Microstructural and Magnetic Properties of Lithium Ferrite Films Prepared on SrTiO3 (001) Substrates

This version is not peer-reviewed.

Submitted:

24 September 2023

Posted:

25 September 2023

Read the latest preprint version here

A peer-reviewed article of this preprint also exists.

Abstract
Epitaxial lithium ferrite (LiFe5O8) films with different thicknesses have been successfully fabricated on SrTiO3 (001) substrates by magnetron sputtering deposition technique. The microstructural and magnetic properties are characterized by advanced transmission electron microscope and magnetic measurement device. It was found that the formation of structural defects can be influenced by the thickness of the film. Apart from the misfit dislocations, the orientation domains form in thinner film and twin boundaries appear in thicker film, respectively, contributing to the misfit strain relaxation in the heterosystem. The magnetic measurement shows that the thinner films have enhanced magnetization and a relatively lower coercive field compared with the thicker films containing the antiferromagnetic twin boundaries. Our results provide a way for tuning the microstructure and magnetic properties of lithium ferrite films by changing the film thickness.
Keywords:
Lithium ferrite; film thickness; defects; magnetic properties; electron microscopy
Subject:
Chemistry and Materials Science  -   Electronic, Optical and Magnetic Materials

1. Introduction

Lithium ferrite (LiFe5O8) has drawn widespread attention of research because of its remarkable physical properties, such as high saturation magnetization, high Curie temperature, large electric resistivity, low loss at high frequencies, and good chemical and thermal stability [1,2], which make it have potential application in components of microwave device and spintronics [3,4]. LiFe5O8 has the inverse spinel structure, where the tetrahedral sites are occupied by Fe3+, and the octahedral sites are shared by Li+ and the rest Fe3+ in a ratio of 1:3 (denoted as Fe[Li0.5Fe1.5]O4). The antiparallel aligned magnetic spin between the Fe3+ distributing at tetrahedral sites and octahedral sites leads to a high magnetic moment of 2.5 µB per formula unit [1,5]. Compared to the bulk material, spinel thin films exhibit microstructural variations such as the presence of planar defects, which can alter the electrical and magnetic structures of the films [6,7]. Thus, research efforts concentrating on the growth, structure, property, and applications of the spinel thin films have proliferated over the last decades [8,9,10].
Generally, during the film deposition process, many degrees of freedom can be used to modify the structural and physical properties of the film [11,12,13]. Among them, changing the film thickness is a common method to manipulate the strain state of the film [14,15]. Particularly, tuning strain states not only cause the formation of oriented domains [16,17], but also lead to the different density of antiphase boundaries in spinel films [18,19], which influence the magnetic properties of the films consequently [20]. Moreover, enhanced magnetic moments are present in ultrathin films (e.g., NiFe2O4 and CoFe2O4) prepared on spinel-type MgAl2O4 substrates [21,22,23]. In contrast, there are limited investigations on the microstructural characteristic and magnetic behavior of LiFe5O8 films with different thickness prepared on perovskite-type substrates that are widely used as substrates for growing functional films in device application.
In the present work, the microstructural and magnetic properties of LiFe5O8 films with two different thicknesses prepared on SrTiO3 substrates have been investigated by aberration-corrected (scanning) transmission electron microscopy ((S)TEM) and superconducting quantum interference device (SQUID). The twin boundaries (TBs), orientation domains, and interface dislocation in the films have been determined by high-angle annular dark-field (HAADF) imaging. The magnetic properties of the films have been characterized by magnetization measurement in a SQUID magnetometer, and the effect of film thickness and structure defects on the magnetic properties of the LiFe5O8 films has been discussed.

2. Materials and Methods

LiFe5O8 ceramic target was prepared by a standard solid-state reaction method with the initial reactants Fe2O3 and LiCO3 (ratio 5:2). The LiFe5O8 films with different thicknesses were fabricated on single-crystalline SrTiO3 (001) substrates by a high-pressure sputtering system at the substrate temperature of 800 ℃. The working pressure was 0.5 mbar with the mixed ambient of Ar and O2 at the ratio of 1:1.
(S)TEM specimens were prepared by focused ion beam (FIB) lift-out technique using an FEI Helios600i FIB/SEM system. FIB lamellae were cut along the <110> orientations of the SrTiO3 substrate. TEM and HAADF-STEM experiments were performed on a JEOL-ARM200F with a probe aberration corrector, operated at 200 kV. In STEM mode, a probe size of 0.1 nm at semi-convergence angle of 22 mrad was used for HAADF-STEM imaging. The HAADF detectors covered angular ranges of 90-176 mrad.

3. Results and discussions

Figure 1a and 1b are the low-magnification bright-field (BF) TEM images of LiFe5O8 thin film on SrTiO3(001) substrates with a thickness of 7.5 nm and 30 nm, respectively. The film-substrate interfaces are marked by horizontal arrows. The contrast variation within the film can be discerned in both films. In Figure 1b, the oblique contrast lines shown by blue arrows are apparent. Figure 1c and 1d display the corresponding selected area electron diffraction (SAED) pattern of the heterostructure in Figure 1a and 1b, respectively, recorded along the [10] zone axis of SrTiO3. In Figure 1c, apart from the diffraction spots of the SrTiO3 substrate, two sets of diffraction spots from the LiFe5O8 film can be distinguished, resulting in two film-substrate orientation relationships (ORs) as [10](001)film//[10](001)substrate (cube-on-cube) and [10](111)film//[10](001)substrate. Considering the four-fold symmetry of the SrTiO3(001) substrate surface, there exists an equivalent OR having a 90° in-plane orientation relation to the latter OR. In Figure 1d, the LiFe5O8 film adopts the cube-on-cube OR with the substrate. Instead of forming crystalline orientation domains in the 7.5-nm-thick film, there present some {111} TBs in the 30-nm-thick film. Taking the lattice parameter of SrTiO3 substrate (0.3905 nm) as the calibration standard [24], the in-plane and out-of-plane lattice parameter of the 7.5-nm-thick film is calculated to be 0.8319 nm and 0.8353 nm, respectively. Similarly, in-plane and out-of-plane lattice parameter of the 30-nm-thick film is calculated to be 0.8301 nm and 0.8359 nm, respectively. Both films are under the compressive strain along the in-plane direction [10].
In order to further investigate the microstructure and strain relaxation behaviors, high-resolution HAADF-STEM experiments have been performed. Figure 2a–c are the atomic-resolution HAADF-STEM images showing the interfaces of the 7.5-nm-thick film, viewed along [10] zone axis of the SrTiO3 substrate. Misfit dislocations form at the interface in both heterostructures. For the grain with the cube-on-cube OR (Figure 2a), the projected Burgers vector of misfit dislocations can be determined as (af/4)[110] (af is the lattice parameter of LiFe5O8). For the [10](111)film//[10](001)substrate OR, the misfit dislocations occur at the interfaces, as shown in Figure 2b,c. The projected Burgers vectors are determined to be (af/8)[11] and (af/4)[10], respectively. In contrast, for the heterostructure of the 30-nm-thick film on the SrTiO3(001) substrate, only a number of {111} TBs appear within the LiFe5O8 film as demonstrated in Figure 2d.
Additionally, for the heterostructure of the 7.5-nm-thick film prepared on SrTiO3(001) substrate, the occurrence of two types of film-substrate ORs would form a columnar grain structure in the film. The coalescence of these grains inevitably leads to the formation of grain boundaries (GBs). Figure 3a–c are the HAADF-STEM images containing such GBs. The boundaries appear curved through the film as traced by white dashed lines. It should be emphasized that there is no secondary phase or obvious element segregation at the boundaries.
In the LiFe5O8/SrTiO3 heterostructure, the lattice mismatch is calculated to be about +6.2% for cube-on-cube epitaxy, using the formula [(af-2as)/2as]*100%. For the LiFe5O8(111)/SrTiO3(001) epitaxy, the lattice mismatch along [110]f direction is the same as that of the cube-on-cube epitaxy, whereas the film-substrate lattice mismatch along [11]f direction is much large. According to our experimental results, the strain relaxation behaviors are essentially different for the LiFe5O8 films with different thicknesses prepared on SrTiO3(001) substrates. The appearance of oriented grains and misfit dislocations releases the compressive strain in the 7.5-nm-thick film on SrTiO3 substrate. In contrast, the formation of a high density of twins within the film mainly contributes to the strain relaxation in the 30-nm-thick film.
The magnetic properties of the LiFe5O8 films have been characterized by the magnetic hysteresis loops using the SQUID system. The effect of pure SrTiO3 substrate has been carefully eliminated. Figure 4a,b present the M-H hysteresis loops measured along in-plane and out-of-plane directions of 7.5-nm- and 30-nm-thick film separately. The in-plane saturation magnetization (Ms) of the 7.5-nm-thick film is about 535 emu/cc and the out-of-plane Ms is 443 emu/cc. Both values are significantly higher than that of bulk LiFe5O8 (2.5 µB/formula unit ~ 320 emu/cc) [5]. The in-plane and the out-of-plane Ms of the 30-nm-thick film are about 194 emu/cc and 137 emu/cc, respectively. The in-plane and out-of-plane coercive fields (Hc) of the 7.5-nm-thick film are about 71 Oe and 142 Oe, respectively, which are smaller than that of the 30-nm-thick film (217 Oe and 166 Oe). Our measurement of the magnetic properties shows apparent thickness dependence of LiFe5O8 thin films prepared on SrTiO3(001) substrates.
The enhancement of the magnetic moment and the decrease of the coercive field has been reported in thinner spinel films, e.g., NiFe2O4 and CoFe2O4 [21,22,23] and LiFe5O8 on MgAl2O4 substrates [10]. The anomalous cation distribution among the tetrahedral and octahedral sites of the spinel structure has been invoked to account for this phenomenon [14,21]. In our LiFe5O8 thin films, no chemical modulation or second phase has been observed during TEM investigations, ruling out the anomalous Fe3+ distribution as the origin of the enhanced Ms. Thus, the most likely factor responsible for the thickness-dependent magnetic properties is the strain state and the microstructure of the film. For the inverse spinel structure materials, the compressive strain favors the in-plane orientation of the magnetization [22,25]. Moreover, the magnetic coupling across the nonstoichiometric twin boundaries (TBs) in spinel is antiferromagnetic [7]. Although strain relaxations occur in our LiFe5O8 films, the tetragonal lattice distortions appear in both films under compressive strain, resulting in anisotropic magnetization in the both films. Additionally, the appearance of a high density of antiferromagnetic TBs [26] in the 30-nm-thick film can lower the Ms of the film. In contrast, the oriented GBs are dominant in the 7.5-nm-thick film, which may enhance the Ms of the film owing to the magnetic coupling at the interfaces [9,17]. Overall, varying thicknesses of the LiFe5O8 films on SrTiO3(001) substrate can effectively modify the microstructural and magnetic properties of the film.

4. Conclusion

The epitaxial LiFe5O8 thin films with the thickness of 7.5 nm and 30 nm have been grown on SrTiO3 (001) substrate. Microstructural investigations show that the (111)film//(001)substrate and (001)film//(001)substrate ORs appear in the 7.5-nm-thick film, and TBs occur in the 30-nm-thick film, respectively, which contributes to the lattice misfit strain. Importantly, the 7.5-nm-thick film displays a larger saturation magnetization and a relatively lower coercive field in comparison with the 30-nm-thick film. Our results demonstrate that changing the film thickness could effectively tune the microstructure and magnetic properties in epitaxial LFO thin film.

Author Contributions

Conceptualisation, K.L.; investigation, K.L, R.Z; writing—original draft preparation, K.L.; writing—review and editing, L.L., J.L, S.Z.; supervision, L.L. All authors have read and agreed to the published version of the manuscript.

Funding

This research was funded by the Guangdong Major Project of Basic and Applied Basic Research (No. 2021B0301030003), the Science and Technology Planning Project of Suzhou City (No. SZS2022015), the Natural Science Foundation of the Jiangsu Higher Education Institutions of China (Grant: 21KJB510022) and Cultivation project of Suzhou vocational University (SVU2021py02).

Institutional Review Board Statement

Not applicable.

Informed Consent Statement

Not applicable.

Data Availability Statement

Not applicable.

Acknowledgments

Thanks to Suzhou Key Laboratory of Smart Energy Technology, Jihua Laboratory for the support of experiments of characterization.

Conflicts of Interest

The authors declare no conflict of interest.

References

  1. White, G.O.; Patton, C.E. Magnetic Properties of Lithium Ferrite Microwave Materials, J. Magn. Magn. Mater. 1978, 9(4), 299-317. [CrossRef]
  2. Sugimoto, M. The Past, Present, and Future of Ferrites, J. Am. Ceram. Soc. 1999, 82(2), 269-280. [CrossRef]
  3. Lüders, U.; Barthélémy, A.; Bibes, M.; Bouzehouane, K.; Fusil, S.; Jacquet, E.; Contour, J.-P.; Bobo, J.-F.; J.-F. Fontcuberta, J.-F.; Fert, A. NiFe2O4: A Versatile Spinel Material Brings New Opportunities for Spintronics, Adv. Mater. 2006, 18(13), 1733-1736. [CrossRef]
  4. Suzuki, Y. Epitaxial Spinel Ferrite Thin Films, Annual Review of Materials Research 2001, 31, 265-289.
  5. Boyraz, C.; Mazumdar, D.; Iliev, M.; Marinova, V.; Ma, J.; Srinivasan, G.; Gupta, A. Structural and magnetic properties of lithium ferrite (LiFe5O8) thin films: Influence of substrate on the octahedral site order, Appl. Phys. Lett. 2011, 98(1), 012507. [CrossRef]
  6. Wei, J. D.; Knittel, I.; Hartmann, U.; Zhou, Y.; Murphy, S.; Shvets, I. V. et al. Influence of the Antiphase Domain Distribution on the Magnetic Structure of Magnetite Thin Films, Appl. Phys. Lett. 2006, 89(12), 122517. [CrossRef]
  7. Chen, C. L.; Li, H. P.; Seki, T.; Yin, D. Q.; Sanchez-Santolino, G.; Inoue, K et al. Direct Determination of Atomic Structure and Magnetic Coupling of Magnetite Twin Boundaries, ACS nano, 2008, 12(3), 2662-2668. [CrossRef]
  8. Udhayakumar, S.; Kumar, G. J.; Kumar, E. S.; Navaneethan, M.; Kamala Bharathi, K. Electrical, Electronic and Magnetic Property Correlation Via Oxygen Vacancy Filling and Scaling-law Analysis in LiFe5O8 Thin Films Prepared by Pulsed Laser Deposition, J. Mater. Chem. C 2022, 10(40), 15051-15060.
  9. Liu, X.; Wu, M.; Qu, K.; Gao, P.; Mi, W. Atomic-Scale Mechanism of Grain Boundary Effects on the Magnetic and Transport Properties of Fe3O4 Bicrystal Films, ACS Appl. Mater. and Inter. 2021, 13(5), 6889-6896. [CrossRef]
  10. Zhang, R.; Liu, M.; Lu, L.; Mi, S.B.; Wang, H. Strain-tunable magnetic properties of epitaxial lithium ferrite thin film on MgAl2O4 substrates, J. Mater. Chem. C 2015, 3(21), 5598-5602.
  11. Hu, G.; Choi, J. H.; Eom, C. B.; Harris, V. G.; Suzuki, Y. Structural Tuning of the Magnetic Behavior in Spinel-Structure Ferrite Thin Films, Phys. Rev. B 2000, 62(2), R779-R782. [CrossRef]
  12. Jing, H.M.; Hu, G.L.; Mi, S.B.; Lu, L.; Liu, M.; Cheng, S.D.; Cheng, S.; Jia, C.L. Microstructure and Electrical Conductivity of (Y, Sr)CoO3-δ Thin Films Tuned by the Film-Growth Temperature, J. Alloys Compd. 2017, 714, 181-185.
  13. Foerster, M.; Rebled, J.M.; Estradé, S.; Sánchez, F.; Peiró, F.; Fontcuberta, J. Distinct Magnetism in Ultrathin Epitaxial NiFe2O4 Films on MgAl2O4 and SrTiO3 Single Crystalline Substrates, Phys. Rev. B 2011, 84(14), 144422. [CrossRef]
  14. Rigato, F.; Estradé, S.; Arbiol, J.; Peiró, F.; Lüders, U.; Martí, X.; Sánchez, F.; Fontcuberta, J. Strain-induced stabilization of new magnetic spinel structures in epitaxial oxide heterostructures, Materials Science and Engineering: B 2007, 144(1-3), 43-48. [CrossRef]
  15. Praus, R. B.; Leibold, B.; Gross, G. M.; Habermeier, H.U. Thickness dependent properties of La0.67Ca0.33MnO3 thin films, Appl. Surf. Sci. 1999, 138-139, 40-43. [CrossRef]
  16. Matvejeff, M.; Lippmaa, M.; Growth of InFeCoO4 thin films on SrTiO3 and MgO substrates, J. Cryst. Growth 2010, 312(16-17), 2386-2392. [CrossRef]
  17. Wang, Y.; Li, D.F.; Dai, J.Y. Microstructure and magnetic properties of a novel spinel (Zn,Co)Fe2O4 thin film on the SrTiO3 substrate, J. Cryst. Growth 2010, 313(1), 26-29. [CrossRef]
  18. Moussy, J.B.; Gota, S.; Bataille, A.; Guittet, M.J.; Gautier-Soyer, M.; Delille, F.; Dieny, B.; Ott, F.; Doan, T.; Warin, P.; Bayle-Guillemaud, P.; Gatel, C; Snoeck, E. Thickness dependence of anomalous magnetic behavior in epitaxial Fe3O4(111) thin films: Effect of density of antiphase boundaries, Phys. Rev. B 2004, 70(17). [CrossRef]
  19. Mi, S.B.; Zhang, R.Y.; Lu, L.; Liu, M.; Wang, H.; Jia, C.L. Atomic-scale structure and formation of antiphase boundaries in α-Li0.5Fe2.5O4 thin films on MgAl2O4(001) substrates, Acta Mater. 2017, 127, 178-184.
  20. Gao, C.; Jiang, Y.; Yao, T; Tao, A.; Yan, X.; Li, X. et al., Atomic Origin of Magnetic Coupling of Antiphase Boundaries in Magnetite Thin Films, J Mater Sci Technol. 2022, 107, 92-99. [CrossRef]
  21. Lüders, U; Bibes, M.; Bobo, J.-F.; Cantoni, M; Bertacco R.; Fontcuberta, J. Enhanced Magnetic Moment and Conductive Behavior in NiFe2O4 Spinel Ultrathin Film, Phys. Rev. B 2005, 71(13), 134419.
  22. Gatel, C.; Warot-Fonrose, B.; Matzen, S.; Moussy, J.B. Magnetism of CoFe2O4 Ultrathin Films on MgAl2O4 Driven by Epitaxial Strain, Appl. Phys. Lett. 2013, 103(9), 092405. [CrossRef]
  23. Hoppe, M; Döring, S; Gorgoi, M.; Cramm, S.; Müller, M. Enhanced Ferrimagnetism in Auxetic NiFe2O4 in the Crossover to the Ultrathin-Film Limit, Phys. Rev. B 2015, 91(5), 054418.
  24. Howard, S.A.; Yau, J.K.; Anderson, H.U. Structural Characteristics of Sr1−xLaxTi3+δ as a Function of Oxygen Partial Pressure at 1400 °C, J. Appl. Phys. 1989, 65(4), 1492-1498.
  25. Fritsch, D.; Ederer, C. Epitaxial Strain Effects in the Spinel Ferrites CoFe2O4 and NiFe2O4 From First Principles, Phys. Rev. B 2010, 82(10), 104117.
  26. Liu, K.; Zhang, R.Y.; Lu, L.; Mi, S.B.; Liu, M.; Wang, H.; Wu, S.Q.; Jia, C.L. Atomic-Scale Investigation of Spinel LiFe5O8 Thin Films on SrTiO3 (001) Substrates, J Mater Sci Technol. 2020, 40(1), 31-38. [CrossRef]
Figure 1. (a, b) Low-magnification BF-TEM images and (c, d) the corresponding SAED patterns of 7.5-nm-thick and 30-nm-thick LiFe5O8 film prepared on SrTiO3 (001) substrate, recorded along the [10] SrTiO3 zone axes. The film-substrate interface is indicated by horizontal arrows. The twin boundary is denoted by oblique blue arrows.
Figure 1. (a, b) Low-magnification BF-TEM images and (c, d) the corresponding SAED patterns of 7.5-nm-thick and 30-nm-thick LiFe5O8 film prepared on SrTiO3 (001) substrate, recorded along the [10] SrTiO3 zone axes. The film-substrate interface is indicated by horizontal arrows. The twin boundary is denoted by oblique blue arrows.
Preprints 85990 g001
Figure 2. (a~d) High-resolution HAADF-STEM images of the heterostructures, viewed along the [1 0] SrTiO3 zone axis, showing the formation of misfit dislocations and twin boundaries. The film-substrate interfaces are denoted by horizontal white arrows.
Figure 2. (a~d) High-resolution HAADF-STEM images of the heterostructures, viewed along the [1 0] SrTiO3 zone axis, showing the formation of misfit dislocations and twin boundaries. The film-substrate interfaces are denoted by horizontal white arrows.
Preprints 85990 g002
Figure 3. (a~c) HAADF-STEM images of grain boundaries in 7.5-nm-thick film. The boundaries are denoted by white dashed lines and oblique white arrows.
Figure 3. (a~c) HAADF-STEM images of grain boundaries in 7.5-nm-thick film. The boundaries are denoted by white dashed lines and oblique white arrows.
Preprints 85990 g003
Figure 4. (a, b) In-plane and out-of-plane magnetic hysteresis loops of LiFe5O8 films with different thicknesses measured at room temperature (300 K).
Figure 4. (a, b) In-plane and out-of-plane magnetic hysteresis loops of LiFe5O8 films with different thicknesses measured at room temperature (300 K).
Preprints 85990 g004
