A Switched Capacitor Memristor Emulator using Stochastic Computing

Version 1 : Received: 6 December 2021 / Approved: 7 December 2021 / Online: 7 December 2021 (11:41:20 CET)

How to cite: Benito, C.D.; Camps, O.; Al Chawa, M.M.; Stavrinides, S.G.; Picos, R. A Switched Capacitor Memristor Emulator using Stochastic Computing. Preprints 2021, 2021120100 (doi: 10.20944/preprints202112.0100.v1). Benito, C.D.; Camps, O.; Al Chawa, M.M.; Stavrinides, S.G.; Picos, R. A Switched Capacitor Memristor Emulator using Stochastic Computing. Preprints 2021, 2021120100 (doi: 10.20944/preprints202112.0100.v1).

Abstract

Due to the increased use of memristors, and its many applications, the use of emulators has grown in parallel to avoid some of the difficulties presented by real devices such as variability and reliability. In this paper, we present a memristive emulator designed using a Switched Capacitor (SC), this is, an analog component/ block and a control part or block implemented using stochastic computing (SCo) and therefore fully digital. Our design is thus a mixed signal circuit. Memristor equations are implemented using stochastic computing to generate the control signals necessary to work with the controllable resistor implemented as switched capacitor.

Keywords

memristor; emulator; analog design; switched capacitor; stochastic computing; mixed signal

Subject

ENGINEERING, Electrical & Electronic Engineering
