Preprint Technical Note Version 1 Preserved in Portico This version is not peer-reviewed

Vibration Analysis of Axially Functionally Graded Non-Prismatic Euler-Bernoulli Beams Using the Finite Difference Method

Version 1 : Received: 25 May 2021 / Approved: 27 May 2021 / Online: 27 May 2021 (09:09:32 CEST)

How to cite: Fogang, V. Vibration Analysis of Axially Functionally Graded Non-Prismatic Euler-Bernoulli Beams Using the Finite Difference Method. Preprints 2021, 2021050660 (doi: 10.20944/preprints202105.0660.v1). Fogang, V. Vibration Analysis of Axially Functionally Graded Non-Prismatic Euler-Bernoulli Beams Using the Finite Difference Method. Preprints 2021, 2021050660 (doi: 10.20944/preprints202105.0660.v1).

Abstract

This paper presents an approach to the vibration analysis of axially functionally graded (AFG) non-prismatic Euler-Bernoulli beams using the finite difference method (FDM). The characteristics (cross-sectional area, moment of inertia, elastic moduli, and mass density) of AFG beams vary along the longitudinal axis. The FDM is an approximate method for solving problems described with differential or partial differential equations. It does not involve solving differential equations; equations are formulated with values at selected points of the structure. The model developed in this paper consists of formulating differential or partial differential equations with finite differences and introducing new points (additional or imaginary points) at boundaries and positions of discontinuity (concentrated loads or moments, supports, hinges, springs, and brutal change of stiffness). The introduction of additional points allows satisfying boundary and continuity conditions. Vibration analysis of AFG non-prismatic Euler-Bernoulli beams was conducted with this model, and natural frequencies were determined. Finally, the direct time integration method (DTIM) was presented. The FDM-based DTIM enabled the analysis of forced vibration of AFG non-prismatic Euler-Bernoulli beams, considering the damping. The efforts and displacements could be determined at any time.

Subject Areas

Axially functionally graded non-prismatic Euler-Bernoulli beam; finite difference method; additional points; vibration analysis; direct time integration method
