Impact of a Hybrid Assisted Wheelchair Propulsion System on Motion Kinematics during Climbing Up a Slope

Version 1 : Received: 23 January 2020 / Approved: 24 January 2020 / Online: 24 January 2020 (15:00:13 CET)

A peer-reviewed article of this Preprint also exists.

Wieczorek, B.; Warguła, Ł.; Rybarczyk, D. Impact of a Hybrid Assisted Wheelchair Propulsion System on Motion Kinematics during Climbing up a Slope. Appl. Sci. 2020, 10, 1025. Wieczorek, B.; Warguła, Ł.; Rybarczyk, D. Impact of a Hybrid Assisted Wheelchair Propulsion System on Motion Kinematics during Climbing up a Slope. Appl. Sci. 2020, 10, 1025.

Journal reference: Appl. Sci. 2020, 10, 1025
DOI: 10.3390/app10031025

Abstract

Overcoming terrain obstacles presents a major problem for people with disabilities or with limited mobility who are dependent on wheelchairs. An engineering solution designed to facilitate the use of wheelchairs are assisted propulsion systems. The objective of the research described in this article is to analyse the impact of the hybrid manual-electric wheelchair propulsion system on the kinematics of the anthropotechnical system when climbing hills. The tests were carried out on a wheelchair ramp with an incline degree of 4°, using a prototype wheelchair with a hybrid manual-electric propulsion system in accordance with the patent application P.427855. The test subjects were three people whose task was to propel the wheelchair in two assistance modes supporting manual propulsion. The first mode is hill climbing assistance, while the second one is assistance with propulsion torque in the propulsive phase. During the tests, a number of kinematic parameters of the wheelchair were monitored. An in-depth analysis was performed for the amplitude of speed during a hill climb and the number of propulsive cycles performed on a hill. The tests performed showed that when propelling the wheelchair only using the hand rims, the subject needed an average of 13 pushes on the uphill slope, and their speed amplitude was 1.8 km/h with an average speed of 1.73 km/h. The climbing assistance mode reduced the speed amplitude to 0.76 km/h, while the torque assisted mode in the propulsive phase reduced the number of cycles required to climb the hill from 13 to 6. The tests were carried out at various values of assistance and assistance amplification coefficient, and the most optimally selected parameters of this coefficient were presented in the results. The tests proved that electric propulsion assistance has a beneficial and significant impact on the kinematics of manual wheelchair propulsion when compared to a classic manual propulsion system when overcoming hills. In addition, assistance and assistance amplification coefficient were proved to be correlated to operating conditions and the user's individual characteristics.

Subject Areas

wheelchair; hybrid manual-electric drives; drives supporting the movement
