Preprint Article Version 1 Preserved in Portico This version is not peer-reviewed

Study on Hot Gases Flow in Case of Fire in a Road Tunnel

Version 1 : Received: 27 January 2018 / Approved: 28 January 2018 / Online: 28 January 2018 (17:10:18 CET)

A peer-reviewed article of this Preprint also exists.

Król, A.; Król, M. Study on Hot Gases Flow in Case of Fire in a Road Tunnel. Energies 2018, 11, 590. Król, A.; Król, M. Study on Hot Gases Flow in Case of Fire in a Road Tunnel. Energies 2018, 11, 590.

Abstract

This paper presents the results of hot smoke tests, conducted in a real road tunnel. The tunnel is located within the expressway S69 in southern Poland between cities Żywiec and Zwardoń. Its common name is Laliki tunnel. It is a bi-directional non-urban tunnel. The length of the tunnel is 678 m and it is inclined by 4%. It is equipped with the longitudinal ventilation system. Two hot smoke tests have been carried out according to Australian Standard AS 4391-1999. Hot smoke tests corresponded to a HRR (Heat Release Rate) equal to respectively 750 kW and 1500 kW. The fire source was located in the middle of the road lane imitating an initial phase of a car fire (respectively 150 m and 265 m from S portal). The temperature distribution was recorded during both tests using a set of fourteen thermocouples mounted at two stand poles located at the main axis of the tunnel on windward. The stand poles were placed at distances of 5 m and 10 m. The recorded data were applied to validate of a numerical model built and solved using Ansys Fluent. The calculated temperature distribution matched the measured values.

Keywords

road tunnel; fire; Ansys Fluent; smoke movement; temperature distribution

Subject

Engineering, Civil Engineering
