Abstract
This paper presents an algorithm for the fully automatic mesh generation for the finite element analysis of ships and offshore structures. The quality requirements on the mesh generator are imposed by the acceptance criteria of the classification societies as well as the need to avoid shear locking when using low degree shell elements. The meshing algorithm will be generating quadrilateral dominated meshes (consisting of quads and triangles) and the mesh quality requirements mandate that quadrilaterals with internal angles close to $90\degree$ are to be preferred. The geometry is described by a dictionary containing points, rods, surfaces and openings. The first part of the proposed method consist of an algorithm to automatically clean the geometry. The corrected geometry is then meshed by the frontal Delaunay mesh generator as implemented in the gmsh package. We present a heuristic method to precondition the cross field of the frontal quadrilateral mesher. Also the influence of the order in which the plates are meshed will be explored as a preconditioning step.
Keywords
mesh generation; quad dominated surface meshes; finite element analysis; shell elements
Subject
Computer Science and Mathematics, Applied Mathematics
