Preprint Communication Version 1 This version is not peer-reviewed

Super-Wide Impedance Bandwidth Planar Antenna Based on Metamaterial Concept for Microwave and Millimetre-Wave Applications

Version 1 : Received: 17 April 2019 / Approved: 19 April 2019 / Online: 19 April 2019 (11:36:12 CEST)

A peer-reviewed article of this Preprint also exists.

Alibakhshikenari, M.; Virdee, B.S.; See, C.H.; Abd-Alhameed, R.A.; Falcone, F.; Limiti, E. Super-Wide Impedance Bandwidth Planar Antenna for Microwave and Millimeter-Wave Applications. Sensors 2019, 19, 2306. Alibakhshikenari, M.; Virdee, B.S.; See, C.H.; Abd-Alhameed, R.A.; Falcone, F.; Limiti, E. Super-Wide Impedance Bandwidth Planar Antenna for Microwave and Millimeter-Wave Applications. Sensors 2019, 19, 2306.

Journal reference: Sensors 2019, 19, 2306
DOI: 10.3390/s19102306

Abstract

A novel configuration for a super-wide impedance planar antenna is presented based on a 2 × 2 microstrip patch antenna (MPA). The antenna comprises a symmetrical arrangement of four-square patches that are interconnected to each other with cross-shaped high impedance microstrip lines. The antenna array is exciting through a single feedline connected to one of the patches. The proposed antenna array configuration overcomes the main drawback of conventional MPA of narrow bandwidth that is typically <5%. The antenna exhibits a super-wide frequency bandwidth from 20 GHz to 120 GHz for S11<−15 dB, which corresponds to a fractional bandwidth of 142.85%. The antenna’s performance of bandwidth, impedance match, and radiation gain were enhanced by etching slots on the patches. The slotted microstrip patch essentially acts like a left-handed capacitance to exhibit metamaterial properties over a given frequency range. With the inclusion of the slot the maximum radiation gain and efficiency of the MPA have increased to 15.11 dBi and 85.79% at 80 GHz, which show an improvement of 2.58 dBi and 12.54%, respectively. The dimension of each patch antenna is 30 × 30 mm2. The results show that the proposed MPA is useful for various communications existing and emerging systems such as ultra-wideband (UWB) communications, RFID systems, massive multiple-output multiple-input (MIMO) for 5G, and radar systems.

Subject Areas

array antenna Microstrip Patch Antenna (MPA); slot antenna; metamaterial; Multiple-Output Multiple-Input (MIMO); radar; RFID systems; millimetre-wave band
