Mitochondrial Dysfunction in Cardiac Disease: The Fort Fell

1. Introduction

Heart is like a residence where almost everything is dependent on energetic availability in order to satisfy the everyday needs of each family’s member. Accordingly, myocardial cells and extracellular matrix fulfil their prerequisites thanks to the energetic availability. Indeed, mechanical and electrical properties of the heart are strongly depended on the energetic production-consumption equilibrium. Cardiac fuel is the master key of contraction – relaxation coupling, ion exchange, cell growth, apoptosis, necrosis etc. and serve for the maintenance of cardiac homeostatic procedure. Interestingly, although heart represent 0.5% of body weight, consumes 8% of energy, and the produced ATP supports only a small number of heart beats, forcing the entire metabolic factory to repeat the entire process within few seconds in a way to support the energetic needs [1,2].

There are several forms of produced energy including kinetic, dynamic, thermal energy etc. Notably, under different circumstances such as aging and cardiac disease, although total energy remains constant, the contribution of each energetic sub-form is different. For example, in heart failure patients’ thermal energy is increased, whereas the dynamic and kinetic energy are decreased and unable to satisfy adequately the cardiac work [3]. There is an impairment of energy production and inadequate transfer within cardiac cells proved by the decrease in cellular ATP, phosphocreatine (PCr), and the PCr/ATP ratio, observed in both heart failure with reduce [4] or preserved left ventricular ejection fraction [5]. When this bioenergetic capacity reaches its limit then a decompensate stage begins, the cardiac homeostatic disequilibrium starts, affected by the over activation of sympathetic system, renin-angiotensin-aldosterone axis, inflammation etc., and a vicious cycle leading to heart failure syndrome starts. The metabolic-energetic alteration favors the accumulation of toxic products; unfolded/misfolded proteins, free radicals etc. leading to cardiac micro and macro-architecture change; cardiac remodeling [6]. This bioenergetic capacity; energy production and consumption, depends on cardiac metabolic resources and on the functional status of both cardiomyocytes and non-cardiomyocytes cells and their metabolic - energetic behavior. A behavior that we have to better understand and to further investigate the master key of the process; mitochondria.

2. Mitochondrial Dynamics

Mitochondria are intra-cellular organelles producing more than 95% of ATP. Their normal structure, integrity, function and homeostatic properties are highly important since their unsuitable anatomy and abnormal-altered function are responsible for myocardial cell injury and death and consequently for cardiac disease genesis and progression [1,7,8]. They have their own DNA (mtDNA), circular in shape, encode 13 subunits of protein whereas the majority of the mitochondrial proteins are governed by nuclear DNA, transported within mitochondria via mitochondrial membrane. The mtDNA, because of their own low protective mechanisms, is subjected to mutations responsible for many inherited cardiomyopathies [1]. However, the amount of mutated mtDNA presented in each individual is higher than the incidence of myocardial diseases, serving thus as dormant source for subsequent emerging diseases when mitochondria mutations have reached a certain threshold [9]. On the other hand, gene–gene and gene–environment interactions do not affect proportionally cardiac mitochondria, thanks to the powerful compensatory mechanism that they possess, showing a resistance to outsider harmful events, protecting thus mitochondria malfunction and hence the manifestation of heart diseases [10]. However, when they are severely affected, they face a non-viable situation leading to detrimental effects. Usually are modestly affected, having thus the time to compensate, to rearrange their homeostatic status and change their metabolic actions. If the compensate process fails, then heart diseases emerge and within time progress [11,12,13]. When the heart failure syndrome begins the fission and fragmentation processes are involved and as the syndrome deteriorates there is a decrease in mitochondrial cristae density, areas of cluster mitochondria are observed, vacuolar degeneration and calcium overload is present [13,14,15,16] leading to myocardial cell apoptosis and necrosis [17,18]. As a response, mitochondrial defensive mechanisms are increased, especially mitophagy, trying to protect the myocardial cells and the heart as a whole. This has been reported in both preserved and reduced ejection fraction being more actively involved in the latest [14,19]. However, although the protective mechanisms are beneficial, within time as the syndrome aggravates the protective mechanisms are over whelmed unable to protect and to maintain mitochondria normal function [19,20]. Moreover, the autophago-lysosomal system is dysfunctional [21,22] making thus the mitochondria more vulnerable. The heart failure syndrome of any cause deteriorates, the fort fell, Figure 1.

There are different mitochondrial shapes across the human body depended on the tissue and the adjacent cell environment that can differentiate mitochondria structure-function-behavior. Thus, different mitochondria subpopulations are present demonstrating different response to metabolic–energetic status, underlying thus their complexity heterogeneity and diversity. In the myocardium, the most metabolically active and thus most rich organ in mitochondria, their main role is to regulate biogenesis, ion transport, and to protect themselves using their defensive mechanisms, fusion, fission, mitophagy etc. [23,24], Figure 2. This is accomplished due to the presence of three different mitochondrial subtypes within cardio myocytes, a) interfibrillar, b) subsarcolemmal and c) perinuclear mitochondria, each subtype demonstrating different shape, function – response to metabolic and pathophysiologic changes. Indeed, the interfibrillar are oval, lying in longitudinal rows within myofibrils and exhibit higher rate of oxidation. Subsarcolemmal, are responsible for electrolyte and metabolite transport and offer the higher myocardial protection. Perinuclear, are of spherical shape, control nuclear function, and regulate mostly mitochondria fusion and fission process [23]. Of interest, products of the association of mitochondrial respiratory chain complexes (I–IV) harbored in the inner mitochondria membrane create the mitochondrial super complexes. Their aim is to provide incremental capabilities in the electron transfer process. They constitute the respirasome (I+III₂+IV₁), responsible for mitochondrial and phospholipids (cardiolipin etc.) function, satisfying in a better way the energetic needs of the heart. Additionally, their presence and function reduce the amount of free radical production serving thus as a preventer of a possible mitochondrial dysfunction [25,26]. As mentioned before the main aim of mitochondria is the production of energy. Almost 90% of produced ATP is used to support the contraction-relaxation coupling. The separation and the assembly of actin/myosin are both highly energetic depended procedures and therefore their normal behavior is closely related to the source of energy production. Additionally, ions exchange, mainly CA2+ release and sequestration, require high amount of energy, produced at the site of mitochondria. This factory of energy; mitochondria, must act as quick as possible in order to fulfill the needs of human body. Indeed, under high energetic requirements they have to adapt accordingly and to produce enough energy to satisfy the needs. To accomplish this issue, they possess the capability to protect their self, to interconnect, to change their shape, and to move within the cell since they ‘can cross cell boundaries’ [27]. The need of change in shape and motion may occur under normal circumstances; high load exercise training or under different pathological clinical scenarios; myocardial ischemia, hypertension, cardiac hypertrophy, heart failure etc. In case of mutated or dysfunctional mitochondria etc., the production of energy is inadequate, whereas the accumulation of harmful substances; free radicals’ production, heat shock and unfolded/misfolded proteins, promote the beginning and the progress of cardiac diseases. Keeping with the above-mentioned reports it is clear that mitochondria have to have their own protective mechanisms in order to avoid their dysfunction-malfunction transformation and keep the energetic-metabolic-homeostatic status of the cell on the road. Indeed, mitochondria morphology and function adapt to the different environment, activating their self-protective actions, that is necessary for the cell survival, [23] Figure 2. These actions are under specific protein control; guanosine triphosphate hydrolase enzyme family, mitochondrial fission and fusion proteins, mitochondrial dynamics proteins 49 and 51, etc. Figure 2, facilitate a continuous adaptation of mitochondria shape and function, promote genetic material exchange between the mitochondria, ensuring their ability of optimal function [23,28]. The mechanism through which mitochondria can receive genetic material from the mitochondria of other cells, although not fully elucidated, facilitate inter-cellular molecular crosstalk that represent an adaptive mechanism trying to avoid mitochondria malfunction [27]. Three different modes of inter-cellular mitochondria transport have been proposed a) tunneling nanotubes (TNTs), b) membrane extracellular vesicles (EVs) and c) gap junctions (GJC) [29]. TNTs represent the principal way of mitochondria transport, are formed rapidly by mitochondria membrane protrusions, and are composed of F-actin and transport proteins [30]. Membrane micro-vesicles represent heterogeneous components released from intra to extra cellular environment and thus called extracellular vesicles (EVs). Smaller EVs contain exosomes, small RNAs, genomic DNA, mtDNA, while larger EVs can contain even entire mitochondria [27,31,32]. Their principal role is to eliminate abnormal proteins and can serve as an additional mode for inter cellular communication (in nervous system) [33,34]. GJCs are transport gates for several substances’ transportation including nutrients, metabolites, mitochondria [35] and it seems that play a role for the intercellular transportation of reactive oxygen substances [24,36]. Although, as it has been suggested, mitochondrial structure change is connected to several pathologies, this knowledge is not thoroughly investigated and not used in every day clinical practice [24,37]. The presence of different mitochondrial phenotypes; donut-like, ellipsoid shape etc., as well their side of action may represent defensive response to several harmful events [37,38,39]. A response that can affect the main protective mitochondrial mechanism; fission and fusion. Taken into account the presence of different mitochondrial subpopulations, their altered shape and the role of specific drivers - proteins for fission; mitochondrial fission factor, mitochondrial division 49 and 51 etc., and fusion; mitofusin1, 2 etc. Figure 2, may represent an early sign of a disease and their measurement might facilitate clinical diagnosis. Additionally, the study of mtDNA heteroplasmy (different alleles in one patient) [40] may give us further knowledge about the mitochondrial abnormal status and to let us discover earlier the upcoming consequences.

3. Mitochondria, a ‘Socialized’ Organelle

The cell’s organelles are inter-connected and they function not as a single unit but as a whole, according to the cellular needs [41]. The anatomical and functional communication between them; endoplasmic reticulum (ER), mitochondria, nucleus, plasma membrane, Golgi apparatus etc. is well known, indicating their principal role on human body homeostasis [42,43]. Mitochondria are not formed de novo, do not possess certain abilities (does not synthesize phosphatidylcholine, phosphatidylinositol, sterols, sphingolipids etc.) [43], and necessarily their activities are linked to their action to communicate with the other organelles [41,43].

Are considered as the most ‘socialized’ organelle since are interconnected with a variety of them and their defensive mechanisms; fusion, fission, mitophagy etc. are dependent on their best cross-talk. Of note, mitochondria-lysosome [44,45], mitochondria-peroxisome [46], and mitochondria -lipid droplets [47] communication serve to achieve the optimum homeostatic cell equilibrium and function. Of particular interest is the communication between ER and mitochondria, being in continuous cross-talk, since mitochondrial main function; oxidative phosphorylation and ATP production, Ca2+ exchange and buffering etc., is dependent on ER lipid and Ca2+ transport efficiency [7,43].

3.1. Mitochondria—Endoplasmic Reticulum Connection

The endoplasmic reticulum (ER) is involved in many cellular activities; secretory, protein folding, ions homeostatic process, lipids biosynthesis etc., is connected with the other cell organelles affecting thus their activities. In cardiovascular diseases several causes such as ischemia, pulmonary and arterial hypertension, metabolic disorders etc. can alter ER normal function leading to ER homeostatic imbalance characterized by the production of free radical and misfolded proteins. Consequently, the proper communication between ER and the other cardiomyocyte organelles is disrupted [48], promoting cell apoptosis, necrosis etc. Accordingly, ER–mitochondria interconnection; through mitochondria-associated membranes (MAMs), are responsible for the proper mitochondrial function; cellular metabolism, ions homeostasis, inflammation etc. Indeed, between ER and mitochondria there is an ultrastructural organization that governs various cellular life processes [42] having a crucial role on cardiovascular remodeling and hence to the progress of various cardiovascular diseases [49,50]. The interruption of ER-mitochondria communication produces redox imbalance, further perturbation of ER homeostasis, mitochondrial injury, Ca2+ homeostatic imbalance, energy depletion and programmed cell death. Consequently, myocardial contractility-relaxation coupling along with vascular smooth muscle cell differentiation are affected. Additionally, injured - abnormal mitochondria produce a huge amount of reactive oxygen species, accumulated within the cell inducing further myocardial cell injury and damage. Indeed, in patients with heart failure, the free iron is increased within mitochondria, an ion (through Fenton chemistry) necessary for the free radical production [51]. Regardless of whether mitochondrial or ER is firstly affected, the final result is the loose of homeostatic balance of both organelles as well as their capability of communication, a fact responsible for the incomplete cardiomyocyte reconstruction [52], unbalanced oxidative stress [53], Ca2+ homeostatic incapacity [54], abnormal metabolism of lipid and other substances [55], lack of adequate energy production [42], activation of MAMs, contributors of the genesis of inflammasome and of the inflammation process [56,57], and ultimately cell protection [49]. In other words, when mitochondria/ER structure and function are harmfully affected, the protective homeostatic mechanisms are altered, nuclear and mitochondrial DNA and other toxic substances are released into cytosol [58] indicating the beginning and within time the deterioration of cardiovascular diseases.

Cardiovascular diseases are characterized by the term cardiac remodeling that represent abnormal changes in the structure and function of cardiovascular system [59]. These changes are referred to abnormal response to certain stimuli and are lying on the alteration of inflammatory response, autophagy defect, lack of gene transcription normality, deficient of energy metabolism, increase of oxidative stress, ions homeostasis imbalance, cell apoptotic rhythm, cell necrosis [60,61,62,63,64,65] etc. A response that among other pathophysiological etiologies is due to the sarcoplasmic/endoplasmic reticulum–mitochondria unbalanced coupling [66,67] whereas a balanced coupling is responsible for the stability of the cellular ambient [68]. The normal function of cardiomyocytes, a highly energy demanding cells, are closely dependent on the interconnection between these two organelles, that control among others, Ca2+ buffer and transport [59]. Indeed, mitochondria represent one of the major calcium pools [69] and are part of various biochemical processes; lipid metabolism, calcium signal transduction [70] etc. Similarly, ER is the main Ca2+ homeostatic regulator [71], a site of protein, lipid biosynthesis [72] etc. Consequently, the proper communication between these two organelles is of huge importance since on their collaboration is dependent among others, 2 major properties of myocardial cell; a) the Ca2+ buffer and transport and hence contraction – relaxation coupling and b) the adequate oxidative phosphorylation that cover the myocardial energetic needs, Figure 2 and Figure 3. In this respect, various cardiovascular diseases are promoted by mitochondrial -endoplasmic reticular dysfunctional interconnection as this is shown in cardiac hypertrophy [73], heart failure, cardiomyopathy [74], ischemic heart disease [75], arrhythmogenesis [76] etc.

Calcium is the ion that regulates mitochondrial redox and energy production and during cardiomyocyte contraction, its propagation is observed from endoplasmic reticulum and cytoplasmic towards mitochondria in order to stimulate functions that are necessary for the maintenance of cardiomyocyte bioenergy [59]. However, an incontrollable Ca2+ accumulation has detrimental effect on mitochondria, provoking mitochondrial dysfunction and ultimately loss of cell homeostatic capacity, which can lead to the activation of mitochondrial apoptotic pathway, accentuation of inflammatory procedure, etc. and hence to the beginning and heart failure progress, Figure 3. Interestingly, mitochondrial dysfunction occurs also in those patients with renal insufficiency, insulin resistance etc., co-morbidities that very often coexist in heart failure patients, indicating the main role of mitochondria regarding global human homeostasis and disease progression [77].

3.1.1. Mitochondria and Quadruple Therapy in Heart Failure Patients

The pathophysiological base of heart failure syndrome of any cause and hence its therapeutic approach lies on the treatment of renin-angiotensin-aldosterone system (RAAS) and sympathetic nervous system hyper-activation. This hyper-activation leads to a metabolic disequilibrium, to a large amount of free radical production, and to the activation of the inflammatory process. Accordingly, the recommended therapy for heart failure try to block this hyperactivity, in order to reduce the myocardial oxygen consumption, to reprogram the altered metabolic remodeling and to ameliorate the energetic needs [1,78,79,80,81]. Needs that are closely related to mitochondrial normal function from which the entire myocardial ‘building’ is dependent on. Indeed, beta-blocker therapy reduce sympathetic activity, decrease serum catecholamines level, inhibit mitochondrial fatty acid uptake and increase glucose oxidation trying to compensate the energetic needs of a ‘starving’ heart [82]. While together with the use of RAS blockers reduce free radical production, and inflammation [1,83]. That’s why in patients with heart failure the use of these drugs shows substantial improvement since both drugs, among other beneficial effects, ameliorate the metabolic remodeling and thus the energetic status of myocardial cell [84]. Accordingly, SGLT2 affect metabolic and mitochondrial action [85,86,87] improve mitochondrial energetics and hence myocardial fuel needs [88]. However, even when the recommended for heart failure quadruple therapy is applied the morbidity and mortality rate remain high. It seems therefore that something is missing. Consequently, the scientific research has to try to better understand the metabolic/energetic status of the myocardial cells focused probably on mitochondria-ER homeostasis; interconnection and function.

3.2. Unusual Location of Mitochondria

Another issue that needs further investigation is the discovery of circulating in blood cell-free mitochondria and mitochondrial DNA, released from various cells triggered by stress, injury or disease [89]. Although there are controversial reports it seems that cell-free mitochondria are not energetic active [90]. Their presence in blood raises several questions that have to be addressed and further studies are required. For example, what is the meaning of their presence in healthy and in diseased individuals? Which is their cell-source of origin? Can they serve as therapeutic targets? Their presence in blood represents a non-self-recognized substances and if it is so what is the protective reaction of any single cell and tissue to diminish harmful effects? Interestingly, high levels of circulating cell-free-mtDNA have been found in several clinical scenarios including diabetes, cancer and myocardial infarction, and have been suggested as potential prognostic biomarker [27,91]. Of note, they are not related to any specific cardiovascular disease and are related to cell necrosis, acute respiratory distress syndrome, tumors, and inflammation, of any cause [92,93]. In any case this is an open issue that has to be searched in order to reach the entelechy.

4. Identify Mitochondria Dysfunction: Imaging Techniques and Biomarkers

Although mitochondria are the main player in several cardiac diseases their detection through imaging techniques and/or blood sample analysis are not well known and established. Moreover, some of them do not represent the optimum identifier, are very expensive and therefore not used in every day clinical practice. Additionally, regardless of the used technique it must be taken into account that from the calculated consumed energy only 25% is used for mechanical purposes whereas the remaining is used for non-mechanical actions; metabolism, heat production [94,95] etc. Regarding imaging techniques there are two ways, the invasive and the non-invasive technique, to calculate indirectly the capability of mitochondrial to produce the necessary energy. Using the invasive technique the input energy is measured as the coronary sinus blood flow times the arteriovenous oxygen content difference, whereas the output energy can be calculated using the pressure-volume loop. The non-invasive techniques are represented by positron emission tomography (PET), cardiovascular magnetic resonance spectroscopy [96] and identification of metabolic disturbances in plasma [97].

Regarding PET, carbon-11–labeled acetate (11C-acetate) and oxygen-15–labeled molecular oxygen (¹⁵O2) tracers have been used [95], showing however several drawbacks and therefore with limited application. Phosphorus (31P) magnetic resonance spectroscopy (MRS) can measure endogenous cardiac high-energy phosphate metabolites, creatine kinase (CK) flux [98,99,100] etc. showing the mitochondrial energetic capacity [101,102,103]. In heart failure patients’ mitochondria function is failed, biochemical sequence is altered and hence abnormal substances are utilized. This abnormality can be detected by using metabolomics; however, it is not clear the source of their production making thus this technique less accurate [104,105]. Accordingly, cardiovascular magnetic resonance spectroscopy seems to be a promising technique however due to inherent problems this technique is of limited use [106]. Several other biomarkers have been used but none of them has the potentiality to recognize and give a powerful information regarding mitochondrial function. In this respect, lactate, pyruvate, and lactate: pyruvate ratio, creatine phosphokinase etc. have been used but all of them demonstrate low specificity and sensitivity and have limited power to recognize mitochondrial deficiency. Additionally, the newer proposed biomarkers, growth differentiation factor 15 (GDF-15) and fibroblast growth factor 21 (FGF-21) although of interest show limited diagnostic power [94].

5. Strategies to Keep Mitochondrial Structural and Functional Integrity

Two strategies exist in order to protect mitochondrial integrity; the non-pharmacological and the pharmacological approach. The non-pharmacological consist on the exercise training and on the life style habits. Regarding exercise training although there are not yet conclusive results [23], it is suggested that proper exercise promote changes on mitochondrial function and metabolism [107,108] on mitochondrial fusion and fission protein activity [109] showing a cardioprotective effect [110,111]. Notably, few days of endurance exercise training are enough for mitochondrial protection against ischemic reperfusion injury [112]. Accordingly, although not totally proved, the life style habits and more specifically calorie restriction has been proposed to improve cardiac dysfunction by controlling better cardiac fibrosis, inflammation and mitochondrial defensive mechanisms [113,114].

Regarding pharmacological intervention, the proposed as the optimal medical treatment for patients with heart failure, known as quadruple therapy, contains energetic saving mechanisms for the restoration of mitochondrial function. However regardless of their use the mortality and morbidity rate remain high. Therefore, new medicines are proposed in order to find the right path, in a way to complete the real optimal medical treatment. Thus metabolism (fatty acid, glucose) antioxidants regulators etc. have been proposed [115,116]. Indeed, the control of peroxisome activated receptor-α agonists and L-Carnitine may improve left ventricular function and prevent myocardial fibrosis [117,118]. Accordingly, SGLT2 restore the use of biochemical substances (Fatty acids oxidation/glycolysis) and improve mitochondrial energetic status [119]. Also, metformin, thiazolidinediones, and statins via indirect AMPK activation, stimulate mitochondrial biogenesis [120]. The use of sacubitril/valsartan, cause an increase in natriuretic peptides, mainly αANP [121], restore internal mitochondrial membrane / outer mitochondrial membrane (IMM/OMM) ratio, decrease ROS levels, reinforce autophagy, thus expressing cardioprotective mechanism. The use of antioxidant drugs although an attractive thought, show controversial results. More specifically, the use of Coenzyme Q10 in a study showed an improvement in ejection fraction [122] whereas in another study did not [123]. Mitochondrial pyruvate carrier [124] 1-methyl-4phenyl-1,2,3,6-tetrahydropyridine (mPTP), for example cyclosporine A [125], as well other pharmacological intervention [126,127,128,129,130] have been used but none of them showed robust and conclusive results. There are studies tried to intervene on mitochondrial fusion and fission [131,132,133,134,135,136] mechanism showing an improvement of mitochondrial function whereas others did not [137,138,139,140,141,142]. Thus, based on the previous mentioned knowledge, the need for further investigation is clearly necessary.

6. Future Directions

The interest of the scientific community for mitochondria structure and function is exponential. However, till now there are not enough and robust data that can serve for the identification of malfunctioned ones. Regardless of the progress on this topic many unanswered questions are still on the table and require further elucidation. The diversity of mitochondrial phenotype may guide the determination of different diseases including the cardiovascular diseases [143]. The alteration of their side of action may indicate their different energetic status and probably the beginning of a disease. The reported multi-scale mitochondrial configuration found in different cell types is not clear and may represent a step forward [144]. Moreover, little is known about depletion or alteration of mtRNA that might affect among others the defensive mechanisms [145]. Moreover, not only mrRNA may alter the mitochondrial defensive status but also any harmful event that alter these mechanisms [146]. Again, do MAM’s play a preventive role? Do our everyday habits affect MAM’s and promote cardiovascular diseases [147]? In any case our knowledge remains limited and further effort must be made in order to better understand our factory of energy, especially regarding myocardial mitochondrial cell. Can artificial intelligence can help? This is not known yet and it remains to be answered [148].

7. Conclusions

Through time, regarding heart failure syndrome, an enormous progress is reported. A principal player in heart failure syndrome among others is mitochondria. This is an organelle of huge importance being affected by risk factors, comorbidities, etc. through multifactorial mechanisms leading to the deterioration of this syndrome. Their malfunction demonstrates a bioenergetics decline, a reduced production of energy, ion transport alteration, free radical, misfolded protein production, etc. This malfunction along with the neuro-humoral hyper-activation, leads to the homeostatic mechanisms failure and ultimately drive the whole process to the worse scenario with very severe consequences. In this respect, although many progresses have been made regarding the role of mitochondria in heart failure, there is a need for further investigation in order to understand better the role of this organelle thus finding out hopefully more effective management. The role of mitochondria as a therapeutic target in patients with heart failure is emerged [11], in a way to protect the fort not to fell.
