A General Design Procedure for Symmetrical Windings of Electrical Machines

Massimo Caruso
ORCID logo ,
Antonino Oscar Di Tommaso
* ,
Fabrizio Marignetti
,
Rosario Miceli
,
Giuseppe Ricco Galluzzo
Version 1 : Received: 24 January 2018 / Approved: 25 January 2018 / Online: 25 January 2018 (12:18:58 CET)

A peer-reviewed article of this Preprint also exists.

Caruso, M.; Di Tommaso, A.O.; Marignetti, F.; Miceli, R.; Ricco Galluzzo, G. A General Mathematical Formulation for Winding Layout Arrangement of Electrical Machines. Energies 2018, 11, 446. Caruso, M.; Di Tommaso, A.O.; Marignetti, F.; Miceli, R.; Ricco Galluzzo, G. A General Mathematical Formulation for Winding Layout Arrangement of Electrical Machines. Energies 2018, 11, 446.

Abstract

Winding design methods have been a subject of research for many years of the past century. Many methods have been developed, each one characterized by some advantages and some drawbacks. Nowadays, the star of slots is the most widespread design tool for electrical machine windings. In this context, this paper presents a simple and effective procedure to determine the distribution of the EMF stars and of the winding configuration in all possible typologies of electrical machines equipped with symmetrical windings. Moreover, this procedure can also be easily implemented in a computer program in order to perform automated winding designs for rotating electrical machines. Several examples are provided in order to validate the proposed procedure.

Keywords

Rotating electrical machines; winding design; symmetrical winding; star of slots.

Subject

Engineering, Electrical and Electronic Engineering
