Preprint Article Version 2 This version is not peer-reviewed

Development of Piezoelectric Harvesters with Integrated Trimming Devices

Version 1 : Received: 17 January 2018 / Approved: 17 January 2018 / Online: 17 January 2018 (12:41:48 CET)
Version 2 : Received: 12 March 2018 / Approved: 13 March 2018 / Online: 13 March 2018 (04:42:34 CET)

A peer-reviewed article of this Preprint also exists.

Doria, A.; Medè, C.; Fanti, G.; Desideri, D.; Maschio, A.; Moro, F. Development of Piezoelectric Harvesters with Integrated Trimming Devices. Appl. Sci. 2018, 8, 557. Doria, A.; Medè, C.; Fanti, G.; Desideri, D.; Maschio, A.; Moro, F. Development of Piezoelectric Harvesters with Integrated Trimming Devices. Appl. Sci. 2018, 8, 557.

Journal reference: Appl. Sci. 2018, 8, 557
DOI: 10.3390/app8040557

Abstract

Piezoelectric cantilever harvesters have a large power output at their natural frequency, but in some applications the frequency of ambient vibrations is different from the harvester’s frequency and/or ambient vibrations are periodic with some harmonic components. To cope with these operating conditions harvesters with integrated trimming devices (ITDs) are proposed. Some prototypes are developed with the aid of an analytical model and tested with an impulsive method. Results show that a small trimming device can lower the main resonance frequency of a piezoelectric harvester of the same extent as a larger tip mass and moreover generates at high frequency a second resonance peak. A multi-physics numerical FE model is developed for predicting the generated power and for performing stress-strain analysis of harvesters with ITDs. The numerical model is validated on the basis of experimental results. Several configurations of ITDs are conceived and studied. Numerical results show that harvesters with ITDs are able to generate relevant power at two frequencies owing to the particular shape of the modes of vibration. The stress in the harvesters with ITDs is smaller than the stress in the harvester with a tip mass trimmed to the same frequency.

Subject Areas

harvester; piezoelectric; dynamic vibration absorber; trimming
